- Page 1 DVDO-Xtend-USBC-USB-100 USB-C & USB-A 3.2 Gen 1 100m Extender over HDBaseT User Manual Version v1.0 DVDO │ +1.408.213.6680 │ support@dvdo.com │ www.dvdo.com...
-
Page 2: Table Of Contents
Thank you for purchasing DVDO-Xtend-USBC-USB-100 For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
1. Introduction DVDO-Xtend-USBC-USB-100 is a USB extender that can transmit USB 3.2 Gen 1 signals up to 100m/328ft via a single CAT6a cable. The transmitter features one USB-C host port, one USB-C and two USB-A device ports. The receiver features two USB-C and two USB-A device ports. -
Page 4: Specifications
4. Specifications Technical USB Protocol USB 3.2 Gen 1 Transmission Rate Up to 5Gbps Transmission Distance 100m/328ft via CAT6a (F/FTP) cable 1.5m/4.9ft via USB cable ESD Protection IEC 61000-4-2: ±8kV (Air-gap discharge), ±4kV (Contact discharge) Connections Input: 1× HOST [USB Type C, 24-pin female] Output: 1×... -
Page 5: Operation Controls And Functions
5. Operation Controls and Functions 5.1 Transmitter Panel Name Function Description Uplink USB-C port, connected to PC or host. HOST It can be used for HUB firmware update. USB DEVICES Downlink USB-C port, connected to USB devices such as U disk or hard disk. Its output power is up to 5V/1A. USB DEVICES Downlink USB-A port, connected to USB devices such as (2~3) -
Page 6: Receiver Panel
5.2 Receiver Panel Name Function Description Downlink USB-C port, connected to USB devices such as USB DEVICES 1 U disk or hard disk. Its output power is up to 5V/1.5A. Downlink USB-C port, connected to USB devices such as USB DEVICES 2 U disk or hard disk. -
Page 7: Application Example
6. Application Example 5 /5... - Page 8 Follow us 6 /5 DVDO │ +1.408.213.6680 │ support@dvdo.com │ www.dvdo.com...
