Summary of Contents for DVDO CAT1080-Pair
- Page 1 DVDO-CAT1080-Pair 50m 1080P HDMI Extender User Manual Version: V1.0.0...
- Page 3 DVDO DVDO-CAT1080-Pair 50m 1080P HDMI Extender User Manual Important Safety Instructions 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth. splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
-
Page 4: Table Of Contents
DVDO DVDO-CAT1080-Pair 50m 1080P HDMI Extender User Manual Table of Contents Introduction ...................... 5 Overview ....................5 Features ....................5 Package Contents ..................5 Specifications ................... 6 Panel Description ..................7 Transmitter ..................7 Receiver .................... 7 Installation and Wiring ..................8 Troubleshooting .................... -
Page 5: Introduction
Thank you for purchasing this product. For proper installation and optimum performance, please read the instructions in this manual carefully. DVDO-CAT1080-Pair is a 50m 1080P cost-effective HDMI extender. It supports full HD video, 2ch audio and transports uncompressed 1080P@60Hz signals up to 50m/164ft along a single Cat X cable. -
Page 6: Specifications
DVDO DVDO-CAT1080-Pair 50m 1080P HDMI Extender User Manual Mounting Brackets (with Screws) x 4 User Manual x 1 Specifications Video Input/Output Signal Type HDMI1.3b with HDCP 1.4 Input/Output Resolution 1080@60Hz, including Supported 1080P/1080I/720P/720I Deep Color 8bit Maximum Data Rate 4.45 Gbps... -
Page 7: Panel Description
DVDO DVDO-CAT1080-Pair 50m 1080P HDMI Extender User Manual Panel Description Transmitter Name Description Connect to the power adapter provided. The receiver can be DC 5V powered by transmitter. ON: The transmitter is powered on. POWER LED OFF: The transmitter is powered off. -
Page 8: Installation And Wiring
DVDO DVDO-CAT1080-Pair 50m 1080P HDMI Extender User Manual Installation and Wiring Power Supply Blu-ray Player IR Emitter HDMI IN Power Cat X HDMI OUT IR Receiver Remote Display DVDO-CAT1080-Pair_V1.0.0... -
Page 9: Troubleshooting
DVDO DVDO-CAT1080-Pair 50m 1080P HDMI Extender User Manual Troubleshooting No Power Ensure the power is on. Ensure you use the power adapter provided in the package. No Picture or Video Flash Ensure all devices are on, and all cables are qualified and connected ... -
Page 10: Warranty Terms And Conditions
DVDO DVDO-CAT1080-Pair 50m 1080P HDMI Extender User Manual Warranty Terms and Conditions For the following cases we shall charge for the service(s) claimed for the products if the product is still remediable and the warranty card becomes unenforceable or inapplicable.
