- Page 1 DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Version: V1.0.5...
- Page 2 DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Important Safety Instructions 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth. splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
-
Page 3: Table Of Contents
DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Table of Contents Introduction ...................... 4 Overview ....................4 Features ....................5 Package Contents ..................6 Specifications .................... 7 Transmitter ..................7 Receiver .................... 8 Panel Description ..................9 Transmitter ..................9 Receiver .................. -
Page 4: Introduction
DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Introduction Overview DVDO-PSE-1 is an advanced switching extender set featuring four inputs and UHD scaler. The included transmitter offers two HDMI inputs and one VGA input with stereo audio, and the receiver offers an HDMI input, enabling an additional AV source to be connected at the display location. -
Page 5: Features
DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Features Two HDMI and one VGA inputs included on transmitter One HDMI input, one HDMI output along with one analog audio output included on receiver HDMI inputs support resolutions up to 4K@60Hz YUV 4:2:0 and HDCP 2.2;... -
Page 6: Package Contents
DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Package Contents Before you start the installation of the product, please check the package contents as below: DVDO-PSE-1 (Transmitter and Receiver Set) x 1 DC 12V 3A Power Adapter x 1 ... -
Page 7: Specifications
DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Specifications Transmitter Technical Input 2 x HDMI, 1 x VGA HDMI with 4K (4K@60Hz YUV 420), HDCP 2.2 Input Signal Type VGA: 800x600 , 1024x768 , 1280x768 , 1280x800 1280x960... -
Page 8: Receiver
DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Receiver Technical Input 1 x HDBT, 1 x HDMI HDBT port: HDBT Input Signal Type HDMI port: HDMI, HDCP 2.2 HDMI: 800x600 , 1024x768 , 1280x720 , 1280x768 1280x800 , 1280x960... -
Page 9: Panel Description
DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Transmission Distance Note: The use of T568B straight-through Category cables is recommended. Cable Type Range Supported Video Input: 49ft/15m 1080P@60Hz Output: 33ft/10m HDMI Input: 33ft/10m 4K@60Hz 4:2:0 8bit Output: 16ft/5m 4K@60Hz 4:4:4 8bit... - Page 10 DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Rear Panel Name Description Connect to a PC for firmware update or API command FW UPDATE control. POWER LED On: The transmitter is powered on. (Red) Off: The transmitter is powered off.
-
Page 11: Receiver
DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Receiver Front Panel Name Description Connect to a PC for Telnet API command control. HDBT IN Connect to the transmitter via a CATX cable. HDMI IN Connect to the HDMI source. HDMI OUT Connect to the HDMI display. - Page 12 DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Name Description (Green) Blinking: The link between transmitter and receiver is abnormal. Off: No link AUTO LED On: Input auto switch function is activated (default). (Blue) Off: Input auto switch function is inactivated.
-
Page 13: Installation And Wiring
DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Installation and Wiring Connect the VGA (such as PC) and HDMI sources (such as Blu-ray player, Apple TV, 4K media player, etc) to the VGA IN, AUDIO IN and HDMI IN ports of the transmitter respectively. - Page 14 DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual DVDO-PSE-1_V1.0.5...
-
Page 15: Input Source Switch
DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Input Source Switch This extender set supports auto and manual button switch between the HDBT and HDMI inputs. Auto Switch Press AUTO button, auto switch function will be activated immediately. Priority: HDMI 1 > HDMI 2 > VGA (for transmitter); HDBT > HDMI (for receiver). -
Page 16: Api Command Control
DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual API Command Control DVDO-PSE-1 supports API command control via RS232, FW UPDATE and LAN ports. Example: To power on/off the connected display like projector in real time via API commands, here list the following steps for users’ reference. - Page 17 DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual RS232 port of the receiver. Receiver Telnet Control HDMI IN HDMI OUT RS232 Cable Blu-ray Player Projector Set serial port parameters Suppose the RS232 control codes for your connected projector are as...
- Page 18 DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Control at receiver: enter command “SET UART_INFO 9600 rx” and end it up with CR/LF, click “Send”. Second, set the serial data sending type to hexadecimal format. Control at transmitter: enter “SET UART_DATATYPE hex tx”, end it up with CR/LF, and then click “Send”.
- Page 19 DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Control at receiver: enter “SET UART_DATATYPE hex rx”, end it up with CR/LF, and then click “Send”. Third, edit UART command in hexadecimal format. Set power on command: enter “SET UART_HEX on 50 57 52 20 4F 4E 0D 0A”...
- Page 20 DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual 0D 0A” and end it up with CR/LF, click “Send”. Set UART to power on/off to control the projector Control at transmitter To turn on the projector: enter “SET UART_PWR all on tx”, end it up with CR/LF, and then click “Send”.
- Page 21 DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual with CR/LF, and then click “Send”. Control at the receiver To turn on the projector, enter “SET UART_PWR all on rx”, end it up with CR/LF, and then click “Send”. To turn off the projector, enter “SET UART_PWR all off rx”, end it up with CR/LF, and then click “Send”.
- Page 22 DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Please refer to the API Command Set document for more commands if required. DVDO-PSE-1_V1.0.5...
-
Page 23: Warranty Terms And Conditions
DVDO DVDO-PSE-1 HDBaseT Extender for Presentation User Manual Warranty Terms and Conditions For the following cases we shall charge for the service(s) claimed for the products if the product is still remediable and the warranty card becomes unenforceable or inapplicable.
