- Page 1 2 Port Dual Monitor HDMI KVM Switch (DM7202) User Manual www.kinankvm.com @All right reserved Shenzhen Kinan Technology Co., Ltd. Print Date: 2024/11 Version: V1.0...
- Page 2 Overview Product Description The DM7202 is a 2-port KVM switch that supports 2 monitors and allows users to access two computers with 2 HDMI interfaces via a single USB keyboard and mouse. Setting up the KVM switch is quick and easy, plug the cables into the appropriate ports. The KVM switch takes keyboard and mouse input directly, with no software to set up, no complicated installation procedures, and no compatibility issues.
- Page 3 DM7202 User Manual Rear Panel Components Description Grounding the device Connect to PC1 Input 1-A IN1-A Connect to PC1 Input 1-B IN 1 IN1-B Connect to PC1 Connect to PC2 Input 2-A IN2-A IN 2 Connect to PC2 Input 2-B...
- Page 4 DM7202 User Manual Installation guide Before installation, please make sure all the devices are powered off. Connect the monitor, USB keyboard, and mouse to the CONSOLE port of the device according to figure ②. Connect the server to KVM with HDMI cable, USB cable, and audio cable according to figure ③.
- Page 5 DM7202 User Manual Star to Use Front Panel Buttons Components Description Press button 1-2 to switch between Port1 and Port2. Mouse Switching ： ： Middle + right Middle + left Switch to the previous port Switch to the next port...
- Page 6 DM7202 User Manual Press [L _Ctrl] twice continuously (within 2S interval) to enter the keyboard hotkey mode. If no key is pressed within two seconds in the keyboard hotkey mode, the keyboard will exit the hotkey operation mode. The hotkey commands are as follows: [L _Ctrl] + [L _Ctrl] + the corresponding key for each function.
- Page 7 DM7202 User Manual Specifications Model DM7202 Direct Computer Connections Port Selection Pushbutton, Hotkey, Mouse Monitor 2x HDMI Type A Console Keyboard/mouse 2x USB Type A (White) Audio Output 1x Min Audio Jack (Pink) Connectors Monitor 4x HDMI Type A Keyboard/mouse...
