  • Page 1 USB3.0 2-Port DisplayPort KVM switch www.kinankvm.com @All right reserved by Shenzhen Kinan Technology Co., Ltd. Date:2022/03/03 Version: V1.0...
  • Page 2: User Notification

    DPU202 User Manual User Notification • All information, documents and specifications contained in this manual are subject to change without notice. • The manufacturer does not make any express or implied statements or guarantees regarding the contents of this document, especially for marketability or suitability for any specific purpose.
  • Page 3: Package Contents

    DPU202 User Manual Package Contents 1× DPU202 KVM switch 1× Remote switch cable 3× DP cable 2× USB3.0 cable 2× Audio/Microphone cable 1× Power adapter 1× User Manual • Please check and make sure that all components are present and not damaged during transportation.
  • Page 4: Table Of Contents

    DPU202 User Manual Content User Notification....................... 1 Package Contents ....................... 2 Overview........................4 Product Features....................5 Required equipment....................6 Components.......................7 Front panel......................7 Back panel......................8 Hardware Settings..................... 9 Installation guide....................9 Connection diagram ..................... 10 Hotkey Operation....................11 Specifications......................12 Frequently Asked Questions ................... 13...
  • Page 5: Overview

    This eliminates the need to purchase separate USB hubs or stand-alone peripheral sharers - such as print servers, modems, etc. The DPU202 switch combines Ultra HD 4K resolution, USB 3.0 hub and friendly operation to provide innovative desktop KVM switching technology.
  • Page 6: Product Features

    DPU202 User Manual Product Features A set of USB keyboard and mouse controls two DisplayPort computers.  Support DisplayPort1.2 input and output.  Support display dynamic synchronization, which can optimize the screen display  resolution, reduce the time for switching ports, and ensure that the screen can maintain the original display state when switching between different ports.
  • Page 7: Required Equipment

    DPU202 User Manual Required equipment Refer to the table below to prepare the equipment and cables required for the configuration. DPU202  A DisplayPort monitor  An USB mouse Console  An USB keyboard  Microphone and Speaker  A DP port Computer ...
  • Page 8: Components

    DPU202 User Manual Components Front panel Number Function Description Switch button Press the button to switch to another port Port 1 indicator When switching to port 1, the light is on Port 2 indicator When switching to port 2, the light is on...
  • Page 9: Back Panel

    DPU202 User Manual Back panel Function Function description Power input Connect the 12V power supply here USB peripherals (printers, scanners, drives, etc.) USB HUB port plug into this port Audio output and Connect your speakers and mic here microphone input...
  • Page 10: Hardware Settings

    DPU202 User Manual Hardware Settings To prevent damage to the device from electrical surges or static electricity, it is important that all connected devices are properly grounded. Make sure that all equipment connected to this installation is powered off. You must unplug all computers that have a "keyboard power on"...
  • Page 11: Connection Diagram

    DPU202 User Manual Notice:  By default, the switch is on the first port after power on.  The total length of the cable from the computer to the monitor (including the KVM) should preferably not exceed 3.3 meters. ...
  • Page 12: Hotkey Operation

    DPU202 User Manual Hotkey Operation Press [Scroll-Lock] twice continuously (within 2S interval), if no key is pressed within two seconds under the keyboard hotkey mode, the keyboard will exit the hotkey operation mode. The hot key commands are as follows: double click [Scroll-Lock] plus the corresponding key...
  • Page 13: Specifications

    DPU202 User Manual Specifications Model DPU202 Computer Connections Port Selection Buttons, keyboard hotkeys, remote switching cable Monitor 1x DisplayPort Keyboard/mouse 2 x USB type A (White) Console Microphone (Pink) 1x 3.5mm audio port Speaker (Green) 1x 3.5mm audio port Connectors...
  • Page 14: Frequently Asked Questions

    DPU202 User Manual Frequently Asked Questions Issue Solution Check whether the port indicator on the front panel of the device is on. Check whether the USB cable is connected (USB-B is connected to the KVM end and USB-A is connected to the No display PC host end).
