CAN resistor 120Ω
Screw M6
Expansion screw M6 L80mm
cardboard Positioning cardboard
Battery bracket SGCC T2.0mm
Fixing bracket SGCC T2.0mm
Top cover
SGCC T1.5mm
（Optional）
Wheel
GD40S
（Optional）
Engineering Coordination
Attention should be paid to the following items before construction:
• Power cable specification.
The power cable specification shall meet the requirements of maximum discharge
current for each product.
Mounting space and bearing capacity.
Make sure that the battery has enough space to install, and that the battery rack
and bracket have enough load capacity.
• Wiring.
Make sure the power cable and ground wire are reasonable. Not easy to
short-circuit, water and corrosion.
14
1
1
2
6
1
1
2
1
4
