- Page 1 未找到 图形项 目表。 Tower ESS User Manual...
-
Page 2: Table Of Contents
Tower ESS Unit User Manual Content Statement of Law ......................1 Safety handling of lithium batteries Guide ..............2 1 Introduction ........................ 4 1.1 Brief Introduction ......................4 1.2 Product Properties ......................4 1.3 Product identity definition ....................4 2 Product Specification .................... -
Page 3: Statement Of Law
Tower ESS Unit User Manual Statement of Law Copyright of this document belongs to Daqin New Energy Tech (Taizhou) Co., Ltd. No part of this documentation maybe excerpted, reproduced, translated, annotated or duplicated in any form or by any means without the prior written authorization of Daqin New Energy Tech (Taizhou) Co., Ltd. -
Page 4: Safety Handling Of Lithium Batteries Guide
Tower ESS Unit User Manual Safety handling of lithium batteries Guide symbol ● Battery strings will produce high voltage DC power and can cause a lethal voltage and Danger electric shock. ● Only qualified person can perform the wiring of the battery strings. - Page 5 In case of fire, only dry powder fire extinguisher can be used, liquid fire extinguishers are prohibited; l Please do not open, repair or disassemble the battery except staffs from Dyness or authorized by Dyness. We do not undertake any consequences or related responsibility which because of violation of safety operation or equipment safety standards.
-
Page 6: Introduction
Tower is a high voltage battery storage system based on lithium iron phosphate battery, and it’s one of the new energy storage products developed and produced by Dyness. it can be used to support reliable power for various types of equipments and systems. Tower is especially suitable for application scene of high power, limited installation space, restricted load-bearing and long cycle life. - Page 7 Tower ESS Unit User Manual Battery voltage is higher than safe voltage, direct contact with electric shock hazard. Be careful with your actions and be aware of the dangers. Read the user manual before using. The scrapped battery cannot be put into the garbage can and must be recycled by professional personnel or institutes.
-
Page 8: Product Specification
Tower ESS Unit User Manual 2 Product Specification System Performance Parameter Table 2-1 The parameter of Tower system System List Module Type Total Storing Energy [kWh] 21.31 17.76 14.21 10.66 7.10 Usable Capacity [kWh] 21.31 17.76 14.21 10.66 7.10 Recommend Depth of Discharge... - Page 9 Tower ESS Unit User Manual...
-
Page 10: Battery Module
Tower ESS Unit User Manual 2.2 Battery Module Table 2-2 Product parameters Module Name HV9637 Cell Technology Li-ion(LFP) Battery Module Capacity (kWh) 3.552 Battery Module Voltage (Vdc) Battery Module Capacity (Ah) Battery Module Cell Quantity (pcs) Battery Cell Capacity (Wh) 118.4... - Page 11 Tower ESS Unit User Manual HV9637 top interface HV9637 bottom interface Table 2-3 Interface Definition Item Name Definition Composite connector-Plug Battery module output and communication interface Composite connector-Socket Battery module output and communication interface...
- Page 12 Tower ESS Unit User Manual Composite connector-Plug composite connector-Socket Table 2-4 Port Definition Composite connector-plug Composite connector-socket Negative output Negative output Module positive Module negative 24V+ 24V+ 24V- 24V- SCANH SCANH SCANL SCANL SCANSG SCANSG SWAKE SWAKE...
-
Page 13: Battery Controller
Tower ESS Unit User Manual 2.3 Battery Controller BDU right interface BDU left interface BDU bottom interface... - Page 14 Tower ESS Unit User Manual Table 2-5 Interface Definition Item Name Definition Power Wake Long press this button to start the battery system Button External Positive Connect battery system with Inverter positive terminal socket EXT-CAN RJ45 communication port between the battery system and...
- Page 15 Tower ESS Unit User Manual Caution: When the DC breaker is tripped off because of over current or short circuit, must wait after 30min to turn on it again, otherwise may cause the breaker damage. Power On Button: Generally when it is at ON state, you can’t turn off it during normal running condition Danger: Ensure Power On Switch is turned on before waking up the battery.
-
Page 16: Installation And Configuration
Tower ESS Unit User Manual 3 Installation and Configuration 3.1 Environmental Requirement 3.1.1 Cleanliness The battery system has high voltage connectors. The environment condition will affect the isolation performance of the system. Before installation and system power on, the dust and iron scurf must be removed to keep a clean environment. -
Page 17: Tools
Tower ESS Unit User Manual 3.3 Tools The following tools are required to install the battery pack:... -
Page 18: Safety Gear
Tower ESS Unit User Manual NOTE: Use properly insulated tools to prevent accidental electric shock or short circuits. If insulated tools are not available, cover the entire exposed metal surfaces with available insulated alternatives, except their tip, with electrical tape. -
Page 19: Equipment Installation
Tower ESS Unit User Manual Tower BDU 504*380*156.5mm 1 PCS Battery Module 96V/37Ah 4 PCS HV9637 504*380*240mm Tower Base 504*380*186mm 1 PCS Standard,Black Communication /L2000mm /RJ45 1 PCS cable to inverter plug at both sides Cross recessed countersunk M4*10 20 PCS... - Page 20 Tower ESS Unit User Manual 1.The environment is meeting all technical Installation Step1 preparation requirements: “3.1.1~3.1.6” 1. Determine Tower placement 2. Place the base Mechanical Step 2 installation 3. Install battery module 4. Install Tower BDU 1. Battery system grounding (After the HV9637 module is stacked up and down, it is fixed by two screws on the left and right sides.
- Page 21 Tower ESS Unit User Manual ● Install all the HV9637 modules on the base from bottom to up,follow the sequence B04~B01. Referring to the following figure. ● Each module uses 4 screws to fix. Warning: Single battery module is 41kg. It’s necessary to arrange more than 1 person to install battery module if without lifting equipment, more than 2 person when install battery module in higher position.
- Page 22 Tower ESS Unit User Manual ● After the HV9637 module is stacked up and down, it is fixed by two screws on the left and right sides. After the screw is fixed, the shell surface of the upper and lower modules is fixed and contacted together through screws.There is a special docking point at the bottom of the battery...
- Page 23 Tower ESS Unit User Manual 3.6.4.3 Press the “POWER WAKE” button for about 3S. The system start-up. Press and hold on 3s 3.6.4.4 Use a multimeter to measure the output voltage on the positive and negative ports of the 3.7.4.5 The output voltage should conform to the voltage range in the table “Table 2-1 The parameter of Tower system”...
- Page 24 Tower ESS Unit User Manual 3.6.5 Connecting inverter Caution: A external DC Breaker that operates both positive and negative conductors simultaneously between the BDU and inverter on the power cable is recommended. After waking up the BDU and ensure that the BDU is pre-charged, you can turn on it.
-
Page 25: Maintenance
Tower ESS Unit User Manual Connect to inverter DC+ terminal Connect to inverter DC- terminal Connect the EXT-CAN communication cable to the inverter RJ45 CAN port. ● Connect to inverter RJ45 CAN communication port Warning: Double check all the power cables and communication cable. Make sure the voltage of the Inverter is in the same level with the battery system. -
Page 26: Replacement Of Main Component
Tower ESS Unit User Manual The battery has no voltage output, but The relay in BDU is faulty Replace a new BDU directly “POWER ON”/“POWER WAKE” are on Check whether there is a When the battery is The circuit between the... -
Page 27: Storage Recommendations
Tower ESS Unit User Manual [Periodical Maintenance] The battery system will become unbalanced if have not be charged fully for a long time. Solution: Preform the balancing maintenance (fully charged) every 3 month. Generally this maintenance progress needs to be completed when external devices such as the monitor software and battery and inverter are in good communication. - Page 28 Daqin New Energy Tech (Taizhou) Co., Ltd. Address: Building 13, Kunshan Jiangyan Industrial Park, Chenzhuang West Road, Jiangyan District, Taizhou City, Jiangsu Province, China, 225500. Email: Sales@dyness-tech.com Website: www.dyness-tech.com.cn...
