Summary of Contents for Studer next1
- Page 1 power...
- Page 2 Está a punto de instalar y de utilizar un equipo de alta gama que desempeñará una función esencial en la gestión de energía de su sistema con almacenamiento. El next1 es nuestro inversor/cargador de baterías inteligente monofásico que incorpora las funciones más avanzadas.
-
Page 3: General Information
Studer disclaims all responsibility and liability for damage, costs or losses resulting from an installation that does not comply with the instructions, a faulty operation or inadequate maintenance. The use of studer equipment is in any case under the responsibility of the customer. -
Page 4: Mounting And Installation
Mounting and installation Storage and content 60°C -20°C Mounting place The next1 and batteries should only be installed by qualified personnel. IP65 Ventilated area Out of child's reach... - Page 5 Fixing and dimensions 340mm min. 150mm min. 150mm min. 150mm 182mm 439mm...
- Page 6 Wiring 2’ AC loads AC source AC ex input/output RTC battery AC ex programmable AC load/source up to 2 x 25mm cable, 3.5Nm Battery connection input/output must be con gured as AC ex up to 2 x 16mm cable, 1.5Nm load for ac-solar BAT+, M8 2 x 50mm...
- Page 7 • min 16mm , same Communication section as the AC studer nx communication bus 2x RJ45 cables up to 25mm Warning do not mix with ethernet! Display off – AC source not present or deactivated white on – device is on AC ex as source on –...
- Page 8 Impedancia de terminación de cadena. Multi units parrallel biphased / threephased Up to 3x next1 in parallel per phase Up to 3x next1 in parallel per phase 1 internal transfer, common or separate battery 1 internal transfer, common battery single AC source...
- Page 9 Powering up and con guration via WI-FI ~60s with studer monitoring app Apple Android without the aplication, page 10 sans l'application, page 10 ohne die Applikation, Seite 10 download / open the app sin la aplicación, página 10 open studer monitoring...
- Page 10 < WI-FI studer-next-... WI-FI connection password: studer- Device access point name next-..___________________ studer-next-..************** Device access point password ************* connect Chrome https://stud... https://stud... Firefox Login default username user security user-..warning studer.local Safari...
-
Page 11: Technical Data
Technical data IP 65 inverter nx1 6500-48 nx1 4500-48 Protection Continuous Power 4500 VA 3500 VA Class I Power 30min 6500 VA 4500 VA Power 5sec 12000 VA 12000 VA AC output voltage 230V Phase to Neutral 230V Phase to Neutral AC output frequency 50/60Hz 50/60Hz... -
Page 12: Maintenance And Recycling
Para la Call our specialists +41 27 205 60 80 or visit studer-innotec.com/support Studer Innotec SA rue des Casernes 57 1950 Sion, Switzerland info@studer-innotec.com Studer Innotec SA - V1.0 Data may change without any notice...
