Echosounder Configuration
Parameter
MODE
RANGE_M
RAW_LOG
SERIAL_DEVICE
TXLENGTH_US
Echologger ECT D052/D032 Configuration
Parameter
[ECHOLOGGER_DUAL]
ALT_THRESHOLD_HIGH_PCT
ALT_THRESHOLD_LOW_PCT
BAUD_RATE
DEADZONE_HIGH_MM
DEADZONE_LOW_MM
INTERVAL_S
Copyright © 2019—2025, SPH Engineering
Default Value Description
NMEA
8 Measuring range, m
Log the raw data from echosounder
false
(used for debugging only)
SkyHub 2:
/dev/ttymxc1 Serial device name. Default value
SkyHub 3: depends on the SkyHub generation
/dev/ttyAMA3
Transmitted pulse length, micro
second.
50
The value is automatically increased if
it is less than the required value.
Table 7.19 — Echologger ECT D052/D032 settings
Default Value Description
Altimeter threshold in percents of a full
10
scale for high acoustic frequency
Altimeter threshold in percents of a full
10
scale for low acoustic frequency
115200 UART baud rate, bps
Near field zone where detection is
500 ignored for high acoustic frequency,
mm
Near field zone where detection is
ignored for low acoustic frequency,
1000 mm. To support D032 model
recommend changing the value to 1500
mm.
0.1 Time between measures, sec
91
• NMEA: Ouptut data in NMEA
format only
• ECHOSOUNDER: Output data in
NMEA and SEG-Y formats
