Setup Interface to DJI Autopilot
M300 / M350
Access to Onboard File System
One may use any SCP client to access the SkyHub file system. For example, one may use
WinSCP.
While pressing the Login button one may choose between login via SCP (to have access to the
file system).
Home directory
for root user
Configuration file
Logs directory
Setup Interface to DJI Autopilot M300 / M350
DJI Obstacle Sensors Disabling
Depending on the used payload, downwards obstacle sensors may need to be disabled on DJI
M300 / M350. Should use DJI Pilot to disable them according to the screenshots below.
Copyright © 2019—2025, SPH Engineering
Figure 4.3 — WinSCP settings
/root/
/etc/skyhub/skyhub.conf
/data/skyhub_logs/
16
SkyHub User Manual
Table 4.1 — Onboard File System
