110CR425A/W
Welcome to Follett
Follett equipment enjoys a well-deserved reputation for excellent performance, long-term reliability and outstanding
after-the-sale support. To ensure that this equipment delivers that same degree of service, review this guide carefully
before you begin your installation.
Should you have need technical help, please call our Technical Service group at (877) 612-5086 or (610) 252-7301.
Please have your model number, serial number and complete and detailed explanation of the problem when
contacting Technical Service.
Getting Started
After uncrating and removing all packing material. Inspect the equipment for concealed shipping damage. All freight
is to be inspected upon delivery. If visible signs of damage exist, please refuse delivery or sign your delivery receipt
"damaged." Follett Customer Service must be notified within 48 hours. Wherever possible, please include detailed
photos of the damage with the original packaging so that we may start the freight claim process.
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
Symphony Plus
Ice and Water Dispensers
Please visit https://www.follettice.com/technicaldocuments
for the Operation and Service manual for your unit.
110FB425A/W
110 Series
™
110FB414A/W
Installation Guide
Installation and Service Videos:
www.follettice.com/servicevideolibrary
01568385R00
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Follett Symphony Plus 110 Series
Summary of Contents for Follett Symphony Plus 110 Series
- Page 1 If visible signs of damage exist, please refuse delivery or sign your delivery receipt "damaged." Follett Customer Service must be notified within 48 hours. Wherever possible, please include detailed photos of the damage with the original packaging so that we may start the freight claim process.
- Page 2 § This appliance is not suitable for installation in an area where a water jet could be used. § Connect to potable water supply only. § Follett recommends a Follett water filter system be installed in the ice machine inlet water line (standard capacity, high capacity, carbonless high capacity).
- Page 3 § Routine adjustments and maintenance procedures outlined in this manual are not covered by the warranty. § Maintain all minimum clearances. DO NOT obstruct vents or openings. § This appliance must not be cleaned by a water jet. § Connect to potable water supply only. §...
-
Page 4: Ventilation Clearances
Electrical § Freestanding models require a dedicated circuit. Total system Max. circuit Basic electrical: 115 V/60 Hz/1 phase 11.0A § Dispensers and ice machines are supplied with 7-foot power cord with NEMA 5-15 hospital-grade plug. Connect to a dedicated 15A circuit. Model Electrical connection Circuits required... -
Page 5: Installation
Installation Before you begin § All dispensers must be installed level in both directions to ensure proper operation. § All countertop dispensers provide the option of taking utilities out the bottom or back of the dispenser. See counter cut-out (Fig. 2) for bottom exiting utilities on units with and without drain pans. For installations where utilities will exit through back of dispenser, refer to back view drawings. -
Page 6: Cleaning And Sanitizing
Follett recommends sanitizing the pressurized water lines prior to cleaning the ice machine/dispenser. Follett offers two kits: order P/N 01089572 when a Follett filter system with a pre-filter bowl is present, or P/N 01089580 when a Follett filter system is not present. Follow the instructions provided with the respective kits to sanitize the pressurized water lines immediately before cleaning the ice machine/dispenser. -
Page 7: Semi-Annually (More Often If Conditions Dictate)
SafeCLEAN Plus Solution: Follow the directions on the SafeCLEAN Plus packaging to mix 1 gal. (3.8 L) of Follett SafeCLEAN Plus solution. Use 100 F (38 C) water. [OPTIONAL] No-rinse Sanitizing Solution: Follow the directions on the Nu-Calgon IMS-III packaging to mix 1 gal. -
Page 8: Ice Machine And Dispenser
Ice Machine and Dispenser Cleaning Procedure Note: Check drains and drain cup to ensure they are open and flowing freely. 1. If ice machine was running recently, ensure that the evaporator is completely free of ice before proceeding. If there is ice in the evaporator, complete steps 2-7 using only hot water to remove the ice, then begin Cleaning/Descaling Procedure again. - Page 9 Finish cleaning – SafeCLEAN Plus only 12. Remove top bearing insulation. Loosen Phillips-head screw on nozzle connected to evaporator. Remove nozzle from evaporator side only, leave other side of nozzle connected to transport tube. 13. Soak both Sani-Sponges in remaining SafeCLEAN Plus solution. 14.
- Page 10 18. Remove top bearing insulation. Loosen Phillips-head screw on nozzle connected to evaporator. Remove nozzle from evaporator side only, leave other side of nozzle connected to transport tube. 19. Soak one SaniSponge in remaining sanitizing solution. Insert the sponge soaked in sanitizing solution into nozzle, then insert a dry sponge into the nozzle.
-
Page 11: Dispenser Troubleshooting
Dispenser troubleshooting CAUTION! § Disconnect power to unit before putting hands or arms in storage area or attempting any repair or service to equipment. Before calling for service 1. Check that no ice is in the dispenser bin area. 2. Check that congealed ice is not causing a jam. 3. - Page 12 Warranty Registration and Equipment Evaluation Thank you for purchasing Follett ® equipment. Our goal is to deliver high value products and services that earn your complete satisfaction by delivering high-value products and services backed by outstanding customer and technical support.
