A S S E M B L Y & I N S T A L L A T I O N G U I D E
APPLICATION
Jeep Gladiator
BEDXTENDER HD™ shown assembled and installed on truck.
Remove contents from box and check for damage.
Verify all parts against parts list.
Read and understand instructions completely before attempting assembly
and installation.
REALTRUCK TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 8:00 AM - 5:00 PM EST
Designed and manufactured by AMP Research
Patent Protected. Please see our product site for applicable patents. www.realtruck.com/b/amp-research/
© 2024 AMP Research • Three-year limited warranty. • Professional installation is recommended.
www.realtruck.com
• Made in Mexico
®
1/6
PART #
74833-01A(Black)
INSTALLATION TIME
1 Hour
SKILL LEVEL
2 3
1
TOOLS REQUIRED
Phillips screw driver
Torx T-25 driver
Power drill
9/64" drill bit
Center punch
Supplied templates
Soapy Water
Measuring Tape
Painter's tape
WARRANTY
3-Year Limited Warranty
4
1= Easy
rev 04.22.24
Advertisement
Related Manuals for REALTRUCK AMP RESEARCH BedXTenderHD 74833-01A
Summary of Contents for REALTRUCK AMP RESEARCH BedXTenderHD 74833-01A
- Page 1 Read and understand instructions completely before attempting assembly WARRANTY and installation. 3-Year Limited Warranty REALTRUCK TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 8:00 AM - 5:00 PM EST Designed and manufactured by AMP Research • Made in Mexico ®...
- Page 2 Quick Mount Strap Buckle Assembly Bumper Phillips head PT-Screw Bracket Set screw (included in 74608-01A) Pivot Upright Assembly Bumper Upright Inner Bumper Upright Outer Double Bend Center Tube (With AMP Logo) Double Bend Center Tube (Without AMP Logo) www.realtruck.com rev 04.22.24...
-
Page 3: Universal Mounting Bracket Installation
If equipped with a bedliner, drill through bedliner. Fasten mounting brackets using the supplied self-tapping Phillips screws and torque to 30 in. lbs. If equipped with a bedliner, install mounting brackets over bedliner. www.realtruck.com rev 04.22.24... - Page 4 Repeat for the other side. installed mounting brackets. To keep tube overlap constant, adjust each tube so that the gap between the edge and the tape is the same. Note: Install Strap Buckle Assembly to center tube of Pivot Upright Assembly. www.realtruck.com rev 04.22.24...
- Page 5 When the BEDXTENDER is at the furthest rear position, push down on the buckle to insert into tailgate latch. Tighten straps. NOTE: Ensure that buckles are properly inserted into latches by pulling on the straps after both buckles have been inserted. www.realtruck.com rev 04.22.24...
- Page 6 The straps will be secured on the bottom clips when Bed Extender is flipped in, this will leave the top clips free to use to hold grocery bags if needed. Closing tailgate to keep cargo secured in bed. www.realtruck.com rev 04.22.24...
- Page 7 • Faster and easier access to customer service and tech support in the unlikely event you need warranty or product support. • Registration helps us keep you up to date on product information and offers. To view other Realtruck products that may be offered for your vehicle. Please visit: www.realtruck.com Rev 03.26.24...
-
Page 8: Limited Warranty
LIMITED WARRANTY REALTRUCK warrants product to be free from defects in material and workmanship, for terms specified below, provided there has been normal use and proper maintenance. All remedies under this warranty are limited to the repair or replace- ment of any item found by the factory to be defective within the time period specified. - Page 10 Drill template for BEDXTENDER HD™ mounting brackets 1.28” NOTE: FOR TRUCKS WITH BEDLINERS, USE THIS TEMPLATE ON TOP OF BEDLINER. DO NOT CUT BEDLINER! 1.81” 1.28” 1.81” 1.3” 1.56” 1.3” 1.56” 8” 6.7” TRUCK BED TRUCK BED...
