C-8. MATCHING THE 10 kO RESISTORS.
a. Rebuild the matching bridge as shown in
Figure C -2.
~
is a series string of the 10
matched 1 kO resistors.
b. Set null voltmeter to the 30
J.l
V range and
check meter zero.
c. Apply 20 Vdc to the bridge from the Model
740B.
d. Adjust R3 for a null indication on the Null
Voltmeter, 30
J.lV
range. Do not adjust any
of the 10 matched 1 kO resistors. If adjusting
R3 does not produce null, adjust R1 or R2 until
null is achieved.
ALWAYS DE-ENERGIZE THE 740B
OUTPUT WHEN MAKING CHANGES
IN THE MATCHING BRIDGE SETUP.
e. Replace R
x
(10 - 1 kO resistors) with one of
the six remaining 10 kO resistors.
