Quick Start Guide
HP 71209A Microwave
Spectrum Analyzer
ABCDE
HP Part No. 71209-90001
Printed in USA
October 1991
Edition B.0.0
www.valuetronics.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 71209A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HP 71209A

Summary of Contents for HP 71209A

  • Page 1 Quick Start Guide HP 71209A Microwave Spectrum Analyzer ABCDE HP Part No. 71209-90001 Printed in USA October 1991 Edition B.0.0 www.valuetronics.com...
  • Page 2 Notice The information contained in this document is subject to change without notice. Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and tness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 3 WARNING Before applying power to this instrument, make sure it has been properly grounded through the protective conductor of the ac power cable to a socket outlet provided with protective earth contact. Any interruption of the protective (grounding) conductor, inside or outside the instrument, or disconnection of the protective earth terminal can result in personal injury.
  • Page 4 The HP 71209A - At A Glance The HP 71209A modular spectrum analyzer has a full-band sweep from 100 Hz to 26.5 GHz and built-in external millimeter mixer capability. The standard system consists of an HP 70909A RF section, the HP 70004A color display, the HP 70001A mainframe, the HP 70900B local oscillator module, the HP 70902A and HP 70903A IF sections, and an HP 70310A precision frequency reference.
  • Page 5 (instrument preset key) sets the microwave INST PRESET key spectrum analyzer to a preset condition. execute instrument or display functions, lower-level softkeys DISPLAY MENU USER depending on whether 4 5 , 4 5 , or 4 5 was selected. These softkeys are also dependent upon which menu softkey is selected and can have several levels, each accessed by pressing the bottom softkey.

  • Page 6: In This Book

    In This Book About This Book This HP 71209A Modular Spectrum Analyzer Quick Start Guide provides step-by-step instructions for some of the most common tasks for the HP 71209A modular spectrum analyzer. How To Use This Book Start with the quick overview of the product on the preceding two pages of this book.
  • Page 7 Example 9. Format a memory card and save a trace 1-19 : : : : Example 10. Execute the HP 70000 Customer Demo Downloadable Program (DLP) 1-23 : : : : : : : : : : : : : : : : : : : : : : : : : : : : :...
  • Page 8 www.valuetronics.com...
  • Page 9 Functions When using this quick start guide with an HP 70205A graphics display or an HP 70206A system graphics display, the hardkey panel is not available. However, the hardkey-panel functions are available for all displays and can be accessed by using the softkey path listed below.
  • Page 10 HP 70004A All Displays Hardkey Panel Softkey Path CENTER NNNNNNNNNNNNN NNNNNNNNNNNNNNNNNN Freq CENTER SPAN NNNNNNNNNNNNN NNNNNNNNNNNNN Freq SPAN START FREQ NNNNNNNNNNNNN NNNNNNNNNNNNNNNN Freq START STOP FREQ NNNNNNNNNNNNN NNNNNNNNNNNNN Freq STOP REF LEVEL NNNNNNNNNNNNNNNN NNNNNNNNNNNNNNNNNNNNN Amptd REF LVL NORMAL NNNNNNNNNNNNNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN...
  • Page 11 Before starting the tasks in this chapter, make sure that your system is properly connected. The standard system con guration rear-panel Spectrum Analyzer connections are shown below. Refer to the HP 70000 Installation System and Veri cation Manual for alternative system con gurations, if necessary.
  • Page 12 Make sure that the spectrum analyzer is set to a known state by Example 1. Set up and setting up and initializing the system with this example. This initialize the system ensures that the local-oscillator module is in control and that the menu softkeys that contain the spectrum-analyzer functions are displayed.
  • Page 13 NEXT INSTR DISPLAY display appears. This key sequence should display the HP-MSIB address of the HP 70900B local-oscillator (master) module at the bottom of the display screen when the spectrum-analyzer display appears. For example: Row 0 Column 18: 70900B,Lo/Ctlr 3.

  • Page 14: Instr Preset

    INSTR PRESET 1. Press The HP 71209A modular spectrum analyzer is placed in a known state by setting all spectrum-analyzer functions to their preset state. 2. Connect the 300 MHz CALIBRATOR output to the RF INPUT connector on the HP 70900B front panel.
  • Page 15 NNNNNNNNNNNNNNNNNNNNNNN 4. Press CAL ALL NNNNNNNNNNNNNNNNNNNNNNN Pressing executes all internal signal-path calibration CAL ALL routines that take approximately 2 to 3 minutes to complete. After the routines are nished, the instrument resumes the state at which the calibration routines were initiated. In this case, the instrument-preset state is resumed.
  • Page 16 For demonstration purposes and convenience, use the calibrator Example 3. Measure a signal to measure a continuous-wave (CW) signal. continuous-wave signal NNNNNNNNNNNNNN Freq 1. Press NNNNNNNNNNNNNN Freq Pressing accesses the frequency menu of softkeys and automatically activates center frequency. NNNNNNNNNNN 2.
  • Page 17 6. Note the frequency and amplitude values of the calibrator signal. The calibrator signal frequency and amplitude values will be displayed in the active-function readout area on the display screen as shown in the following gure. System Measurement Tasks www.valuetronics.com...
  • Page 18 Use signal tracking as a convenient method to keep the signal Example 4. Measure a onscreen while centering it. CW signal using signal 1. Press track 4 INSTR PRESET 5 Pressing resets the system and places it in a known 4 INSTR PRESET 5 state.
  • Page 19 A carrier-to-noise measurement can be made very simply by using Example 5. Make a the delta-marker function. This can be demonstrated by using the carrier-to-noise calibrator signal, placing a marker at the peak of the signal, then measurement placing a delta marker somewhere in the noise. The carrier-to-noise measurement result is displayed in the active function area and is normalized to a 1 Hz bandwidth.
  • Page 20 Pressing NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN turns on the marker-noise function. MKNOISE On Off The spectrum analyzer enables sample detection mode and performs a digital average for 16 bits around the active marker. The marker readout in the active function area on the display reads out the di erence between the markers in dBc/1 Hz.
  • Page 21 The di erence between two traces can be measured very easily Example 6. Measure using the delta-marker function. This example demonstrates the the difference between delta-marker function while measuring the calibrator signal when it is two traces connected and not connected. 1.
  • Page 22 7. Note the amplitude di erence between the two traces. The amplitude di erence between the two traces is displayed in the active-function readout area on the display. 1-14 System Measurement Tasks www.valuetronics.com...
  • Page 23 The calibrator signal can be used to simulate a source and its Example 7. Measure harmonics. In this case, the calibrator signal is the fundamental. the fundamental and With the fundamental and harmonics all visibly displayed at the harmonics of a source same time, the measurement can be made easily with the markers.
  • Page 24 NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN 6. Press RIGHT PEAK NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN Successively pressing enables you to continue RIGHT PEAK measuring the third and higher harmonics. See the gure below. 1-16 System Measurement Tasks www.valuetronics.com...

  • Page 25: Limit Lines

    Build a test limit line around the 300 MHz calibrator signal. By Example 8. Create a using the limit-line editing functions and the knob, limit lines can be limit line created very quickly. 1. Press 300 MHz, and 1 MHz. INSTR PRESET CENTER SPAN...
  • Page 26 to slope. Since slope is always set as the default type, there is no need to make this selection at this time. Slope connects two segments in a line. NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN 6. Press , then and repeat steps 3 NEXT SEGMENT FREQ VALUE through 6 until all segments for your limit-line table have been created.
  • Page 27 Example 9. Format a card. Information from the spectrum analyzer is sent via the MSIB memory card and save path to the HP 70004A's display where the memory card reader is a trace located. 1. Check that the memory card \write protect" switch is o .
  • Page 28 MENU 5. Press MENU Pressing accesses the menu softkeys that contain the spectrum-analyzer functions. 1-20 System Measurement Tasks www.valuetronics.com...
  • Page 29 4 4 5 This key sequence speci es that mass storage information for the HP 70900B local oscillator will be sent to the display at HP-MSIB address 4 (default address). The mass-storage device link between the spectrum analyzer and the display is now established so that they communicate properly.
  • Page 30 NNNNNNNNNNNNNNNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN CATALOG 1 of 2 FORMAT CONFIRM FORMAT 7. Press , then This key sequence formats the HP-MSIB card that is in the memory-card reader. NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN SAVE TRACE A 4 SAVE 5 4 1 5 8. Press on the hardkey panel,...
  • Page 31 A set of four example DLPs are downloaded into the HP 71209A system before it is sent out from the factory. A package containing these DLPs is included with your shipment if these DLPs are missing.
  • Page 32 In using the DLPs, you will nd that they are self-explanatory NNNNNNNNNNNNNNNNNNNNNNNNNNNNN and very easy to use. Use the softkey to display more DLP Intro information regarding DLPs. 5. To exit the HP 70000 Customer Demo DLP, press NNNNNNNNNNNNNN EXIT NNNNNNNNNNNNNN Pressing from any of the four program demonstrations EXIT places you back at the beginning of the DLPDEMO program.
  • Page 33 If the memory card has been selected, make sure that a memory card has been properly inserted. If the HP-IB disk has been selected, make sure that the disk has been properly installed in the correct disk drive. Check that the selected mass storage device is addressed correctly.
  • Page 34 www.valuetronics.com...
