Associated Electrics RC10GT Instruction Manual page 8

8
:: Transmission Build :: Transmission Build - Bag C
:: Transmission Build :: Transmission Build - Bag C
7661
RC10GT
Transmission
Case
:: Transmission Build :: Transmission Build - Bag C
Bearing
3/16 x 5/16
Slipper
washers
Diff
spring
5-40
Locknut
- Bag C - Step 2 - Step 2
6575
Diff bolt
cover
x2 x2
3976
Bearing
3/8 x 5/8
- Bag C - Step 3 - Step 3
x5 x5
4-40 x 3/8
SHCS
4-40 x 3/16
BHCS
- Bag C - Step 4 - Step 4
1/8 x 5/16
bushing
x4 x4
3977
Bearing
3/16 x 3/8
6583
Clutch
hub
6584
Clutch
outer hub
x2 x2
7538
Brake
bracket
Idler gear
and shaft
7669
Driveshaft
spacer
7661
RC10GT
brake
adapter
Drive shaft
6585
Slipper
disk
7663
Spur gear,
64T, 32P
7538
Brake
shoe
6570
6571
Drive gear
7665
roll pin
7553
Brake disk
