  • Page 2 Thank you for purchasing this Team Associated product. This assembly manual contains instructions and tips for building and maintaining your new RC10GT Kit. Please take a moment to read through this manual to help familiarize yourself with these steps. We are continually changing and improving our designs; therefore, actual parts may appear slightly different than in the illustrations.
  • Page 3 :: Hardware - 1:1 Scale View :: Hardware - 1:1 Scale View Cap Head (shcs) Button Head (bhcs) Flat Head (fhcs) 4-40x1/4” 4-40x5/16” 4-40x3/16” 4-40x5/16” 4-40x3/8” 4-40x1/4” 4-40x3/8” 4-40x5/16” 4-40x1/2” 4-40x1/2” 4-40x1/2” 4-40x3/4” 4-40x5/8” 4-4x5/8” 8-32x1/4” (6316) 4-40x3/4” Diff Balls 4-40x1”...
  • Page 4 This symbols indicates a line up your hardare with the correct drawing special note or instruction until you find the exact size. in the manual. Associated Electrics, Inc. Customer Service 21062 Bake Parkway Tel: 949.544.7500 Lake Forest, CA 92630 Fax: 949.544.7501 http://www.AssociatedElectrics.com •...
  • Page 5 4-40 nut 4-40 nut 6271 thin Ballstud .20 (silver) 7806 RC10T front arms (Left & Right) 7813 7809 7537 RC10T RC10T RC10GT king pin 4-40 x 1/2” front front (.125 x 1.11) SHCS bulkhead shock tower Build left and right sides!
  • Page 6 Steering Build - Bag A - Bag A - - Step 5 Step 5 4-40 nut 7809 7809 RC10T RC10T 7307 7307 bumper bumper RC10GT RC10GT nose plate, nose plate, gold gold 6316 8-32 x 1/2 4-40 x 5/16 steel FHCS FHCS...
  • Page 7 7667 washer Diff 7664 outdrive Diff gear 6574 7666 Diff thrust Diff drive 7666 balls, 5/64” rings Diff drive rings 6589 6582 Bearing Diff thrust 6573 5/32 x 5/16 spring Diff thrust bolt 7668 6575 RC10GT Diff Diff thrust outdrive...
  • Page 8 7669 3977 Driveshaft Bearing spacer 3/16 x 3/8 :: Transmission Build Transmission Build - Bag C - Bag C - Step 3 - Step 3 7661 RC10GT 4-40 x 3/8 brake SHCS 6583 adapter 7661 Clutch RC10GT Transmission Case 6584...
  • Page 9 7538 Brake cam clip :: Rear End Rear End Build Build - Bag D - Bag D - - Step 1 Step 1 7533 6299 RC10GT rear E-clip arm mounts (small) 7806 RC10T rear arms 6316 7813 8-32 x 1/2...
  • Page 10 :: Rear End Rear End Build Build - Bag D - Bag D - - Step 3 Step 3 7535 7541 RC10GT RC10GT rear rear univeral 7359 bulkhead drive shaft Bearing 1/4 x 3/8 4-40 thin 1/4 axle 6273 shims Ballstud .30 (silver)
  • Page 11 :: Rear End Rear End Build Build - Bag D - Bag D - - Step 6 Step 6 7535 4-40 nut RC10GT rear bumper 4-40 x 3/8 4-40 x 3/8 SHCS FHCS :: Shocks Build Shocks Build - Bag E...
  • Page 12 :: Shocks Build Shocks Build - Bag E - Bag E - Step 3 - Step 3 Front Rear 6420 / 6421 Shock Shock Shock cap o-ring 6420 / 6421 Shock downstops 6420 / 6421 Shock pivot ball 6420 / 6421 Shock rod Build two front and two rear! :: Shocks Build...
  • Page 13 - Bag E - Step 7 - Step 7 RC10 shock #4 aluminum bushing washer 4-40 locknut 7533 3.1x5.5x2mm RC10GT rear Washer arm shock mounts 4-40 x 5/8 4-40 x 1/2 SHCS Build left and right sides! SHCS Build left and right sides!
  • Page 14 :: Turnbuckles :: Turnbuckles Build Build - Bag F - Bag F - Step 2 - Step 2 6279 Ball cups (white) 7253 Turnbuckle (2.62”) Front Camber Turnbuckle 1.95” (49.5mm) Orient the notch to the left throughout the car. It indicates which end has the Recommended turnbuckle lengths are left hand threads!
  • Page 15 Wheel and Tire Build - Bag G - Bag G - Step 1 - Step 1 TIP: It is recommended to glue the tire beads to the wheels! 7840 RC10GT front 7840 wheel, wide, RC10GT front spacer wheel, wide, inner...
  • Page 16 Fuel Tank / Servo Build - Bag H - Bag H - Step 3 - Step 3 Servo horn and screw not 7719 5407 included! Red o-ring RC10GT Fuel tank 4-40 x 5/16 SHCS #4 aluminum washer Servo not included! 4-40 x 5/16 FHCS...
  • Page 17 Engine not 4-40 x 1/2 Engine included! SHCS adapter, rear #4 aluminum washer Flywheel shim 7625 Engine 7603 adapter, front RC10GT clutch Flywheel washer 7601 7610 RC10GT RC10GT 4-40 x 5/8 clutch 2-shoe BHCS shoes flywheel :: Engine / Exhaust Install...
  • Page 18 :: Engine / Exhaust Install Engine / Exhaust Install - Bag I - Bag I - Step 4 - Step 4 7734 Manifold 4-40 7728 gasket locknut RC10GT Zip ties tuned pipe 5407 Exhaust manifold, non-pull start 7733 RC10GT exhaust...
  • Page 19 :: Throttle and Brake Links Throttle and Brake Links - Bag J - Bag J - Step 2 - Step 2 BRAKE LINKAGE Add a #7560 collar onto the second rod and secure it about 3/8” (9.53mm) from the end of the threads. See drawing below. Bend the brake rod according to the actual size drawing below, including the angled bend at the short side.
  • Page 20 :: Fuel Tubing Install - Bag Misc. - Step 1 :: Fuel Tubing Install - Bag Misc. - Step 1 FUEL TUBING Slide one end of the #7724 fuel tubing onto the fuel tank outlet fitting. Bring the other end of the tubing over to the other fitting.
  • Page 21 :: Antenna, Receiver, Body Install - Step 1 6727 4-40 x 5/16 6338 Servo tape BHCS Antenna tube and cap 6131 RC10GT Receiver not wing included! 6131 RC10GT body, clear 4-40 locknut :: Antenna, Receiver, Body Install - Step 2...
