Associated Electrics RC10 B74.2D TEAM KIT Manual

1:10 scale 4wd electric off road competition buggy kit
Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the RC10 B74.2D TEAM KIT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Associated Electrics RC10 B74.2D TEAM KIT

Summary of Contents for Associated Electrics RC10 B74.2D TEAM KIT

  • Page 2 • FT Universal Tire Balancer (#1498) • Calipers or a Precision Ruler • Soldering Iron • FT Dual Turnbuckle Wrench (#1114) • Green Slime shock lube (#1105) Associated Electrics, Inc. Customer Service 21062 Bake Parkway. Tel: 949.544.7500 Lake Forest, CA 92630 Fax: 949.544.7501...
  • Page 3 :: Hardware - 1:1 Scale View :: Hardware - 1:1 Scale View Button Head (bhcs) Flat Head (fhcs) Ball Bearings 2x4mm (31510) 2x3mm (91743) 4x7x2.5mm (31732) Aluminum (8545) 3x8mm (25201) 2.5x5mm (31519) Titanium (91592) 5x8x2.5mm (31400) 2.5x6mm (31520) 3x10mm (25202) Titanium (91593) 5x10x4mm (91560) 2.5x8mm (31521)
  • Page 4 Each part in the foldout has a number assigned to it for ordering This symbol indicates a Racers Tip. replacement parts. Associated Electrics, Inc. Customer Service 21062 Bake Parkway. Tel: 949.544.7500 Lake Forest, CA 92630 Fax: 949.544.7501...
  • Page 5 6/22 :: Bag 1 - Bag 1 - Step 1 Step 1 25215 92113 Chassis Locknut Brace, 92113 Rear Chassis 92315 Brace, B74 .2 Front Chassis 92112 Side Guards, 25202 (left & right) M3x10mm FHCS 25201 25201 3x8mm M3x8mm FHCS FHCS :: Bag 1 Bag 1 - - Step...
  • Page 6 :: Bag 2 - Bag 2 - Step 1 Step 1 3.5x47.5mm 92122 B74 Arm 00000 mount, B 92313 0x0mm Suspension 92313 XXXXX arm shim 92014 Suspension arm, front Arm mount inserts 25201 92187 M3x8mm Hinge pin, FHCS 3.5x47.5mm :: Bag 2 - Bag 2 - Step 2 Step 2 92014...
  • Page 7 :: Bag 3 - Bag 3 - Step 1 Step 1 Build x2 (1 front, 1 rear) 92306 92306 Diff sun gear, LTC 5x8.5x0.2mm shim 00000 0x0mm 92135 XXXXX Diff case, front/rear 92138 Diff cross 92138 92133 Diff pin Diff o-ring 92306 92262 Diff planet...
  • Page 8 :: Bag 4 - Bag 4 - Step 1 Step 1 Build front gearbox 91563 92139 M10x15x4 Diff shim 92309 bearing 92324 B74.2 front M5x10x4 gearbox, flanged bearing inboard, 0 92319 Diff pinion gear shim, M5x6.5x1mm 92142 Diff pinion 0 & 2 are included in kit. gear “0”...
  • Page 9 :: Bag 4 - Bag 4 - Step 4 Step 4 Start by shimming the diff with one 25211 shim on either side of the diff. If the diff M3x10mm is tight when inserted into the gearbox, BHCS remove one shim from the ring gear side and add it to the diff case side.
  • Page 10 :: Bag 5 - Bag 5 - Step 1 Step 1 Build front shock tower 92314 B74.2 front shock tower, 41095 gull wing M3x22mm LP SHCS 91048 ballstud Tuning Tip: Use the shorter location 92159 25215 for less steering and more stable Shock M3 Locknut front end, although this might slow...
  • Page 11 :: Bag 6 - Bag 6 - Step 1 Step 1 31400 31521 M5x8x2.5mm 92257 M2.5x8mm M2.5x8mm bearing B74.1 BHCS steering 91047 rack 31383 ballstud spacer 92167 Steering bellcrank 31382 input arm 92166 92166 spacer Steering Steering 25215 bellcrank, bellcrank, 91048 right left...
  • Page 12 :: Bag 7 - Bag 7 - Step 1 Step 1 Build x2 91048 91047 (1 left side, 1 right side) 25187 ballstud 31532 M3x14mm ballstud M3x8mm BHCS BHCS 31383 92272 91676 25215 spacer Steering Caster hat M3 locknut block arm bushing, 92171 thick...
  • Page 13 :: Bag 8 - Bag 8 - Step 1 Step 1 Rear Axle Height 91047 92180 +3mm ballstud Rear hub link mount 92267 Rear hub 31383 and insert +2mm (+1mm) spacer +1mm 31383 spacer 89202 +0mm M3x12mm BHCS :: Bag 8 - Bag 8 - Step 2 Step 2 91436...
  • Page 14 :: Bag 9 - Bag 9 - Step 2 Step 2 92308 92335 Ballcup, 3.5x42mm Orient the notch to the left straight turnbuckle throughout the car. It indicates which end has the left hand threads! 22.5mm Build x2 (1 left side, 1 right side) :: Bag 9 - Bag 9 - Step 3 Step 3...
  • Page 15 :: Bag 10 - Bag 10 - Step 1 Step 1 92292 92292 92306 92306 Diff pin Diff pin Diff sun Diff sun gear, LTC gear, LTC 92306 92306 5x8x0.2mm 5x8x0.2mm shim shim 92145 Diff case, 92146 92138 center Diff cap, Diff cross center Fill diffs to this level...
  • Page 16 :: Bag 11 - Bag 11 - Step 1 Step 1 31510 31510 M2x4mm M2x4mm BHCS BHCS Mount the shock pistons with the 91937 number facing up! 91936 FT 13mm 89278 FT 13mm 89278 shock piston, M2.5mm shock piston, M2.5mm 2mm (2x1.7) washer 2mm (2x1.6)
  • Page 17 :: Bag 11 - Bag 11 - Step 4 Step 4 91926 Shock Bleeding Steps: 13mm Before assembly, get each bleed screw and Shock Cap 31510 thread it 1-2 turns into the shock cap, then remove the screw. This will make it easier Shock Fluids: 2x4mm when you are bleeding your shocks.
  • Page 18 :: Bag 12 - Bag 12 - Step 1 Step 1 91997 B6.1 ball ends 92164 1.3mm - Rear 30° anti-roll Front Front Front Front 1.2mm - Front bar pivot 25225 4671 M3x3mm M3x10mm set screw set screw Rear Rear Rear Rear 92291...
  • Page 19 :: Bag 12 - Bag 12 - Step 4 Step 4 31500 M3x2.5mm set screw :: Bag 12 - Bag 12 - Step 5 Step 5 0mm/flush 92309 Gearbox anti-roll bar 31511 M2x5mm SHCS Rear view, the linkage pivot Rear view, the linkage pivot should sit directly above should sit directly above the pivot on the arm.
  • Page 20 :: Bag 13 - Bag 13 - Step 2 Step 2 31805 #1596 Servo thread lock Outer servo (Not included) 31531 mount M3x6mm BHCS 92240 Servo mount brace 92274 Servo mount 41089 M3x6mm LP SHCS :: Bag 13 - Bag 13 - Step 3 Step 3 91049 10mm...
  • Page 21 :: Bag 13 - Bag 13 - Step 5 Step 5 Receiver (Not included) 41090 (Not included) M3x10mm LP SHCS 6727 Servo tape :: Bag 13 - Step 6 There are two cut line options on the rear wings. Carpet The lower one is for carpet setup, the higher one is for dirt setup.

  • Page 22: Tips For Beginners

    :: Bag 13 - Bag 13 - Step 8 Step 8 Trim the body using the pictures below as your guides. :: Bag 13 - Bag 13 - Step 9 Step 9 Rear tire Rear tire insert 91150 Front tire Rear wheel M4 LP steel wheel nuts...
  • Page 23 :: Tuning Tips - Front Arm Mount Pill Insert Setups :: Tuning Tips - Front Arm Mount Pill Insert Setups Insert Hole Locations Standard Position Possible Insert Locations The aluminum front arm mounts A Mount utilize eccentric pill inserts to make Use this position as Number indicates 1/.5...
  • Page 24 Kit Setup - Dirt Driver: Driver: Event: Event: Date: Date: Track: Track: Qualify: Qualify: Main: Main: Finish: Finish: Best Lap Time: Best Lap Time: Front Suspension: Front Suspension: 18mm Ride Height: Axle Height: -1deg Camber: Toe: 1deg Ball Stud Spacing: Front Chassis Brace Screws: Ball Stud Spacing: 1.2mm...
  • Page 25 Driver: Driver: Event: Event: Date: Date: Track: Track: Qualify: Qualify: Main: Main: Finish: Finish: Best Lap Time: Best Lap Time: Front Suspension: Front Suspension: Ride Height: Axle Height: Camber: Toe: Ball Stud Spacing: Front Chassis Brace Screws: Ball Stud Spacing: Anti-Roll Bar: Steering Plate: Arm Type:...

This manual is also suitable for:

90037Rc10 b74.2 team kit90036
