Associated Electrics RC10GT Instruction Manual page 7

:: Servo Saver :: Servo Saver Build Build - Bag B
7255
Servo
saver
:: Servo Saver :: Servo Saver Build Build - Bag B
x2 x2
5-40
locknut
7306
Servo saver
screw, short
FHCS
:: :: Transmission Build Transmission Build - Bag C
- Bag B - - Step 1 Step 1
Ballstud
.20 (silver)
- Bag B - - Step 2 Step 2
3x7x0.5mm
Washer
7306
Servo saver
screw, long
FHCS
- Bag C - Step 1 - Step 1
6581 x12 x12
Carbide diff
balls, 3/32"
7664
Diff gear
52T
7666
Diff drive
rings
6589 x2 x2
Bearing
5/32 x 5/16
7668
RC10GT Diff
outdrive
x4 x4
6271
6271
Ballstud
.20 (silver)
7540
RC10GT
chassis
brace tubes
4-40 x 1/2
SHCS
4-40 x 5/16
SHCS
Diff thrust
washer
Diff thrust
balls, 5/64"
Diff thrust
7255
Servo
saver
Build left and right sides!
6573 x2 x2
6574 x6 x6
6573
bolt
7
Servo saver
spring and
collar
7667
Diff
outdrive
7666
Diff drive
rings
6582
Diff thrust
spring
6575
Diff thrust
nut
