10. Welding
This effect simulates the effect of light from welding and is often used to create a hot,
mechanical atmosphere.
Switch: Turn on/off the effect
DIM: 0%-100% (in 0.1% increment)
CCT: 2800K-6500K
Speed: 1-100
11. SOS
This effect simulates the flashing effect of an SOS signal and is often used to create a
dangerous, distress or emergency atmosphere.

Switch: Turn on/off the effect

DIM: 0%-100% (in 0.1% increment)
CCT: 2800K-6500K
Note: Please rotate the select dial to adjust the parameters, then press and rotate it to the next parameter.
Select manual, the effect can be triggered once by pressing the select dial once. After a certain effect is set,
press MODE button can return to the 11 effects interface.

MENU Settings

Press the MENU button to enter menu
interface, rotate and press the select dial to
enter the following setting options.
1. DMX
Short press the select dial to enter DMX
interface, rotate and press the select dial to
adjust the following settings.
MEMU
DMX
DMX Add
DMX Mode
RDM State
DMX Lost
Termination
Extend DMX Channels
59
60
DMX
60
1
01
On
