Power Adapter MS60PA01
1. Align the light body with the metal contacts at both ends of the power adapter, insert
the power adapter into the slot and press it down, the battery disassemble pusher will
automatically lock with a "click", and the power adapter is installed.
2. Press and hold the battery disassemble pusher, then pull the power adapter out to
disassemble it.
3. Connect the power adapter to power source via the built-in 8-shaped power socket to
power the light body.
8-shaped power socket
Pusher
USB-C output port
Hanging
Hole
Hanging Hole
49
