4. Hold the board by its edges and insert it into the
expansion slot. Align full-size expansion boards with the
guide rail at the front of the system unit.
Press the board firmly into the expansion slot connector.
Gently rock the board from side-to-side to seat it into the
connector.
5.
Insert the screw removed earlier to secure the expansion
board to the support bracket.
6. Attach any signal cables required by the expansion
board.
7.
Replace the system unit cover.
Installing an expansion board
Installing Options 3-11
