CHANGING PROCESSOR JUMPER SETTINGS

The following procedure explains how to locate and change
the jumper setting when you upgrade your processor.
The system power must be off before changing a
jumper setting.
Power off and unplug the system and any peripherals.
1.
Remove the system unit cover (see "Removing the
2.
System Unit Cover" in Chapter 3).
Locate the following jumpers on the system board (see
3.
the following figure).
You may have to remove any installed expansion boards
to access the jumpers (see "Removing Expansion
Boards" in Chapter 3).
5-2 Setting System Board Jumpers
!
WARNING
