Code 340490
Rev. 1
6.3

RADIO CONTROL

The remote control has 6 channels for controlling the adjustable
sun slats, lights, and motorized vertical screens. Rolling code
programming, 868 MHz. Powered by a Lithium Battery type
CR2032.
The transmitter is already matched to the motor
control unit for the Bioclimatic Pergola. The motor
control unit is stored in the transmitter channel/
group 1.

CHAPTER 7: INSTRUCTIONS FOR PROPER INSTALLATION

WARNING: the operations for installation and start-up must be performed only by
professionally qualified and trained staff, in accordance with the regulations in
force.
IMPORTANT: To properly set up the Pergola, follow the "Installation Instructions"
attached to this manual and included in the accessory box or in another part of
the package.
WARNING: the adjustment must be made under safe conditions. There is a residual
risk of crushing/shearing and trapping your fingers, hands or head; therefore,
position yourself outside of the dangerous area.
In particular, in order to avoid the risk of crushing/shearing injuries, do not put
any part of the body between the adjustable blades or between the adjustable
blades and parts of the fixed housing structure (guttering, etc.). This is extremely
important when blades are moving.
OK!
ON
75%
50%
25%
OFF
EVO
CAUTION: The installation includes always several motors with remote control.
Follow the "Installation Instructions" attached to this manual or enclosed in the
accessory box or part of the packaging.
IMPORTANT: after installation the declaration for proper installation must be
compiled by the installer (Sec. 14 par. 1).
www.gibus.com
USE AND MAINTENANCE MANUAL
1 2 3 4 5 6
NO!
33
