IMPORTANT: The installation must be performed
installation instructions and safety rules in force in mobile sites. Be especially
careful when working at height.
The installation isn't usually performed directly by staff from Gibus S.p.A. but by installers
appointed by the authorized dealer, buyer or customer. The client is responsible under the law to
entrust the installation to an expert staff, complying to the installation rules listed in this manual.
In particular follow the "Instructions for proper installation" in Chapter 7. At the time of installation
arrange all the tools mentioned on the first pages of the "Installation Instructions - MOVIE line".
If installers are more than one, it is necessary to appoint an operations co-ordinator.
WARNING: Before use, check that the staging, scaffoldings, ladders and all
personal protective equipment, especially when working at height (harnesses,
safety belts, etc..), comply with the requirements of the current law on safety and
are all in good conditions.
Operators must act in accordance with the safety instructions received. Use
suitable sling devices and provided PPE.
6.1

MECHANICAL STRUCTURE

WARNING: Improper installation can result in bodily injury. Read and carefully
follow the installation instructions (provided with this manual) to properly secure
the structure, so avoiding any risk of falls. At the time of installation arrange all the
tools mentioned on the first pages of the "Installation Instructions - MOVIE line".
WARNING: Check the status of the structure's housing and fixing site before
installing and anchoring the structure to the floor and wall plates.
WARNING: If during installation any structural failures of the seat is noticed (the
absence of the requirements for anchors fixing or other) the installers are required
to provide evidence of this condition to the customer and notify the failure of the
housing site in the section "Installation Notes" on paragraph 14 of this manual. If
the minimum requirements are not satisfied, use other technical solutions, such as
preparing a suitable foundation plinth for each floor plate or use internal counter-
brackets or chemical expansion bolts until the wall is suitable for the installation.
WARNING: the choice of anchors depends on the type and condition of the
housing site.
The instructions on the installation are described in annex "Installation Instructions".
