6.2

ELECTRICAL CONNECTIONS

WARNING: all electrical connections must be made only by professionally qualified
and trained staff, with the power supply cut off (disconnected) and in accordance
with the regulations in force. The product needs a 230V/50Hz power supply. The
power pack on the bioclimatic pergolas has Class II electric insulation level for standard
configuration modules: Blade movement and Spot White lights and RYB. Therefore
the structure must not be earthed. However there is Class I electric insulation when
the optionals and accessories are installed: side drop awnings, antifreeze system or
heaters. In this case (Class I) the structure must be earthed.
WARNING: the vertical side awnings have tubular motors with electrical insulation
levels lower than class II. The bioclimatic pergola must be grounded according to
the diagram shown in the Installation Instructions.
WARNING: even if there are accessories and parts powered at 230V/50Hz with
an electrical insulation level lower than class II (for example antifreeze system
or snowmelt system or heaters applied directly to the pergola), the bioclimatic
pergola must be grounded according to the diagram shown in the Installation
Instructions.
The final implementation of the electrical system must be strictly carried out by a qualified
electrician. Also the technical choices carried out to implement the electrical connections fall
within his competence. Below are the guidelines that should be carefully considered by the
installer who will be charged with the costs of such operating decisions.
Instructions for qualified electrical installers:
IMPORTANT: The electrical system must be carried out according to EN 60335-1
and 2 or subsequent, in force at the time of installation. The degree of protection of
the electrical must be at least IP55. Install an upstream electrical switch suitable
to 230V/50Hz with magnetothermal and differential functions and the features
indicated in the table in paragraph 3.2.
WARNING: The switch shall have at least an IP54 degree of protection if mounted
outside the area accessible to third parties, the degree of protection can be IP40 if the
switch is mounted inside or in areas not accessible to third parties. The switch must be
fixed in a place from where the awning is visible, out of dangerous areas (moving parts)
and at a height from the ground that complies with the regulations in force.
IMPORTANT! Check that the mains voltage is 230 V - 50 Hz.
Standard equipment is meant to be connected to 230v/50Hz electrical mains; for the
installation in countries with different features please specify the requirements when
you place the order! The electrical supply cable must be of double insulation type.
Provide a cable with the features indicated in the table in paragraph 3.2.
WARNING: if the Pergola is installed at a height from the walkable floor lowest than 2,30
m in its lowest travel point, it is necessary to use the "man present" control.
IMPORTANT! The wiring diagrams and installation instructions for the use of
electronic control units are annexed to the control units themselves and should
accompany this manual along with the Installation Instructions and be carefully
stored for subsequent consultations.
