The Bioclimatic Pergolas of the MOVIE line were designed and built according to the principles
of constant innovation, impeccable workmanship and attention to detail by Gibus Total Quality.
A system of values designed to ensure complete customer satisfaction.
Gibus design interacts with nature to obtain maximum comfort and minimum energy waste.
The bioclimatic cover solutions can regulate the microclimate of the environment underneath
by creating natural ventilation. The aluminum blades that make up the cover are moved by
a motorized system and can rotate from the horizontal closed position, which guarantees an
excellent seal in case of rain, to the open position, according to an angle that varies from 0 to 120
degrees. The exposure to sun of the external side of the blades generates heat, which induces
a natural convective movement of air from down to up through the blades. pleasant, refreshing
breeze provides a comfortable environment without any mechanical intervention. Naturally and
without energy consumption.
Adjusting the blades permits modulating the cooling effect and the sunlight that filters into the
environment below, giving full control of the microclimate and one's own comfort. Even if it rains
there is maximum protection because the blades have been designed to waterproof and permit
the flow of water only through the appropriate gutters integrated into the structure columns
(patented Side Seal). Naturally beautiful, efficient and reliable system that Gibus has developed,
filing patents for the innovative technological content.
MOVIE ISLAND is a bioclimatic pergola made of moveable brise soleil aluminium blades and
integrated in a special and dedicated self-supporting structure. It is installed in a stand-alone way
and isolated from any building.
For the MOVIE LEANING VERSION, the structure is dedicated and must be leaned against the
wall of a building.
MOVIE WALL is installed attached to the wall of a building.
The cover is formed of openable and moveable metal blades. When it is sunny, open the blades
to provide the required shade for improved outdoor comfort and a natural airflow that carries
the hot air upwards. When it rains the closed blades offer protection and carry the water to
the gutters incorporated in the supporting structure. The linear motor moves the blades by the
remote control. The Pergola is equipped with several patented systems to facilitate and speed
up the installation work and improve the performance of the product:
®
Gibus Patent
inside edge that provides isolation from the outside.
®
Gibus Patent
from exposed fastening elements.
®
Gibus Patent
Gibus Patent ®
that reduces assembly time in production departments.
Gibus Patent ®
makes it possible to have a strut with drainage on site during installation.
www.gibus.com

CHAPTER 3: TECHNICAL DESCRIPTION

Side Seal: a side holding system for the blades resting on a seal along the
Quick Assembly: quick connection system of the supporting structure free
Blade Seal: blades sealing system.
Smart pin: connection system with a sun slat cap with an integrated linchpin
Screw cap: sealing system for corner drainage with screw cap that also
