3.1

STRUCTURAL AND MECHANICAL COMPONENTS

The Bioclimatic Pergola is formed of a self-supporting structure or attached to a wall, made from
painted aluminium and with side self-supporting gutters, supporting legs measuring 110x110
mm and a cover formed of swinging brise soleil blades.
The couplings include stainless steel brackets, painted aluminium parts, stainless steel nuts
and bolts. The linear actuator is activated by a radio-controlled system and they transmit the
movement to the blades. The profiles are made of aluminium alloy EN AW 6060 UNI EN 573-03
UNI EN 755-2 Qualicoat, treated with an anticorrosion treatment and thermosetting polyester
powder paint. The plastic components are melted in fiberglass and nylon plastic.
ATTENTION!: Corrosion resistance is not guaranteed in the event of immersion or
sprays with salt water (sea storms, etc.). Also, with intense exposure to salty fog,
incrustations or bubbles could appear in the connections or aluminium profiles
and oxide or rust could appear on the stainless steel brackets. These conditions
are not covered by warranty.
3.2

ELECTRICAL COMPONENTS

The sun slats are adjustable thanks to a 24VDC linear actuator governed by an electronic control
unit with a 230VAC/24VDC power supply. The motor provides a maximum push and pull force of
2500 [N]; Protection rating: IP66; Stroke length: 230 mm; Noise level: Max. 60 db (A); Operating
temperature: -20 °C ÷ +60 °C; Control unit with 868 MHz radio receiver, Wi-Fi module for control
with OneSmart App. Internal 100W power supply. Wiring with connectors for motor, wind sensor,
rain sensor. Temperature probe included.
CAUTION: the power supply group has an electrical insulation of Class II. Don't
ground the structure with the following attentions:
WARNING: the vertical side awnings have tubular motors with electrical insulation
levels lower than class II. The bioclimatic pergola must be grounded according to
the diagram shown in the Installation Instructions.
WARNING: even if there are accessories and parts powered at 230V/50Hz with
an electrical insulation level lower than class II (for example, the heaters or snow
melters), the bioclimatic pergola must be grounded according to the diagram
shown in the Installation Instructions.
