Upstream a magnetothermal and differential switch must be installed with the characteristics
defined in the table below. If there is more than one output line from the pergola, each single
line must be protected. Provide power cables as defined in the table below.
MOVIE Electric Features
Power supply 230 V (+10% +15%) 50Hz (*)
Max. absorbed power
Insulation class
Connection mode by IP68 Male/female connector.
Power cable
(supplied by the customer)
For max power:
Up to 30 m
Up to 50 m
Upstream protection
(supplied by the customer)
For max power:
Magnetothermal switch
features:
Protection against
overvoltage
Operating temperature -20°C / +55°C
Degree of protection IP 54
(*) : Or different depending on the place of installation.
(**): If there is more than one output line from the pergola, each single line must be protected.
In the case of antifreeze system, the differential must have an intervention current of 0.01A (dedicated line).
In case of Schuko socket, the differential must be of the AC type and the intervention current of 0.03A.
www.gibus.com
Type Bioclimatic pergola.
100 W (max. 0,5 A) for standard configuration modules.
+max. 250 W with Spot White lights
Tot. max. 600 W (2.7 A)
Refer to the labels on the outputs on each single line.
For the other accessories, refer to the power levels defined in the catalogue.
Class II (the structure must not be earthed) for standard configuration modules
(blade movement and Spot White lights and with RYB).
Class I (the structure must be earthed) with side awnings or heaters).
YOU NEED a double insulated cable. Provide a cable: H07RN-F type with
minimum formation dependent on power
up to 2 kW
3G 1,5 mm
3G 2,5 mm
Magnetothermal switch and differential switch with intervention current 0,03 A.
Type of differential protection: A (**).
up to 2 kW
2 10A poles Curve C
None (provide the electric board with a suitable SPD protection system).
USE AND MAINTENANCE MANUAL
up to 3 kW
2 3G 2,5 mm
2 3G 4,0 mm
up to 3 kW
2 16A poles Curve C
up to 5 kW
2 3G 4,0 mm
2 3G 10,0 mm
up to 5 kW
2 25A poles Curve C
