OPERATION MANUAL
LAC‐1
Laser Area Checker
The LAC-1 Laser Area Checker will confirm location of REDSCAN's detection area by LED and audible indicators.
It will generate 2 steps indicator high or low in order to locate high sensitive detection area.
1. SPECIFICATION
4.5VDC / AAA Alkaline Battery x 3
≪ ≫
Caution
·Supplied batteries may not work for
Power Supply
below-mentioned battery life
due to stocking conditions
·Use alkaline batteries only
Green LED On when power is
supplied
Power Indicator
Green LED blinks for low battery
Red LED Blinks when there is
LED Area Indicator
detection area
Beeps on and off when there is
Audible Indicator
detection area
*Red LED also blinks
45 hours when LED/Audible indicator
Battery Life
operating
4. HOW TO USE
1.Set batteries
2.Turn on power switch to "Audible Indicator On" for easy area check
3.Confirm REDSCAN is operating, and confirm its detection area by LAC-1
・Aim LAC-1 towards REDSCAN
・Move LAC-1 slowly where there may be the detection area
・When LAC-1 is located in the detection area, Red LED blinks and audible
Indicator beeps on and off.
HORIZONTAL DETECTION AREA
REDSCAN
Unit
40°
40°
Side View
＊See <caution> below
<HINTS>
3 LED's indicate detection area sensitivitity independently
to locate high sensitive area precisely.
If one of 3 LED's is blinking
quickly, it stays in high
sensitive area but the others
do not.
5. CHANGING BATTERIES
Power indicator (Green LED) blinks when batteries are exhausted.
1.Press part A and pull it towards you, and remove lid.
2. Insert 3 alkaline AAA batteries by putting (–) end first.
3. Insert the end of lid into the main unit and press it down until it clicks.
A
6. ALERT IF POWER IS NOT OFF
Turn off power after use. If it is left On without receiving detection
area signals for 10 minutes, audible alert is given. Afterwards,
alert is given at 1 minute interval until you turn off power.
2. PARTS IDENTIFICATION
③
②
①
②
①
①LED Area Indicator
②
②Laser Receiver
①
③Power Indicator
(Green LED)
④Power Switch
・OFF
・ON (Audible Indicator Off)
・ON (Audible Indicator On)
4. Confirm High Sensitive Detection Area by 2 step indicator
・LAC-1 in Low Sensitive Area
Red LED blinks slowly and audible indicator beeps on and off slowly in low tone.
・LAC-1 in High Sensitive Area
Red LED blinks quickly and audible indicator beeps on and off quickly in high tone.
VERTICAL DETECTION AREA
REDSCAN
Unit
40°
40°
40°
40°
40°
Top View
Front View
<CAUTION>
・LAC-1 can receive laser beams from REDSCAN within ±40˚. If out
If all 3 LED's are blinking
of this angle, you may not able to have high sensitive indication.
quickly, all stay in high
・Place LAC-1's Indicator side at right angle towards REDSCAN's
sensitive area, namely
Front Window
LAC-1 is located parallel
to detection area
OPTEX INC. (U.S.)
URL: http://www.optexamerica.com
OPTEX DO BRASIL LTDA. (Brazil)
URL: http://www.optex.net/br/es/sec
OPTEX (EUROPE) LTD. / EMEA HQ (U.K.)
URL: http://www.optex-europe.com
OPTEX TECHNOLOGIES B.V.
(The Netherlands)
URL: http://www.optex.eu
OPTEX SECURITY SAS (France)
URL: http://www.optex-security.com
3. DIMENSIONS
④
REDSCAN
Unit
40°
＊See <caution> below
OPTEX CO., LTD. (JAPAN
URL: http://www.optex.net
OPTEX SECURITY Sp.z o.o. (Poland
URL: http://www.optex.com.pl
OPTEX PINNACLE INDIA, PVT., LTD
URL: http://www.optex.net/in/en/sec
OPTEX KOREA CO.,LTD. (Korea)
URL: http://www.optexkorea.com
OPTEX (DONGGUAN) CO.,LTD.
SHANGHAI OFFICE (China)
URL: http://www.optexchina.com
OPTEX (Thailand) CO., LTD. (Thailan
URL: http://www.optex.net/th/th
Copyright (C) 2017 OPTEX CO.,LTD.
No.59-1779-1 2017.4.2
199.5 (7.85)
Unit:mm(inch)
REDSCAN
Unit
40° 40°
Side View
)
