Optex LX-402 Installation Instructions

OUTDOOR PASSIVE INFRARED DETECTOR
LX-402,LX-802N
120°wide Long Range
FEATURES
LX-402 : 12 m (40 ft.) 120° Wide Angle
•
LX-802N : 24 m (80 ft.) Long Range
•
Selectable Detection Area Patterns
•
Day/Night Mode
•
Waterproof (IP Rating: IP54)
•
Safety-Related Precausions
Before Installation, make sure to read this instruction manual carefully for safe and effective product operation.
•
After reading this installation instructions, make sure to keep it in a conveninet place for future use.
•
This icon denotes asituation involving the risk of serious injury
Warning
or even death, if the warning given is ignored.
This icon indicates actions to be avoid. Details of the actions to be
avoided are written beside or near icon.
Never use this product for any application expect purpose for detecting
moving object such as human or car. In addition, never use for any activation
for a shutter or other. It may cause hazards.
Never attempt to disassemble or modify the product, which increases the risk
of fire or damage of the product.
Avoid applying water directly from brackets, houses, or otherwise splashing
water directly onto the product. It increases the risk of damaging the product.
1.INSTALLATION HINTS
2.5 m (8.3 ft.) max.
Maximum mounting height is
2.5 m (8.3 ft.).
1.2 to 1.5 m
(4 to 5 ft.)
When using the pet alley area, the
mounting height should be between
1.2 to 1.5 m (4 to 5 ft.).
2.DETECTION AREA PATTERNS
LX-402
0 5
A. TOP VIEW
m
7
6
5
4
3
2
1
0
1
2
3
4
5
6
7
m
0 1 2
B. SIDE VIEW
1.Multi-Level Area
0 5
m
2.5
2
1
0
0 1 2
2.Pet Alley Area
m 0 5
2.5
2
1
0
0 1 2
FUNCTION
Selectable Plus Count (TEST or 2)
•
Selectable Sensitivity (H, M or L)
•
Form C Relay Output
•
Tamper Switch
•
Mount the detector directly to awall or
celling with the optional bracket (Model
CA-1W or CA-2C).
Avoid looking directly at air conditioning
or heating vents.
ft.
10 15 20 25 30 35 40
25 ft.
20
15
10
5
0
5
10
15
20
ft.
25
3 4 5 6 7 8 9 10 11 12
m
ft.
10 15 20 25 30 35 40
8.3 ft.
5
3 4 5 6 7 8 9 10 11 12
m
ft.
10 15 20 25 30 35 40
8.3 ft.
5
3 4 5 6 7 8 9 10 11 12 m
OPTION
•
•
This icon denotes a situation involving the risk of serious injury
Caution
or damage to property if the warning given is ignored.
This icon indicates instructions that should be stricity followed.
Warning
To avoid the risk of erectric shock, never touch the main body of the
product with wet hands (Also, if the product is wet after rain, do not
touch if).
Never connect the terminal with higher power supply or current draw over
the specification. It increase the risk of fire or damage to the product.
Caution
Clean and inspect the device periodically for safe operation.
If any defect is detected, ask your local shop to repair the device.
Avoid moving objects in the detection
area (i.e.swaying trees, bushs, etc.).
Avoid vapor or high humidity that can
cause condensation.
LX-802
A. TOP VIEW
0 5 10 15 20 25 30
m
1
0
1
m
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
B. SIDE VIEW
1.Multi-Level Area
0 5 10 15 20 25 30
m
2.5
2
1
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
2.Pet Alley Area
0 5 10 15 20 25 30
m
2.5
2
1
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
This product detects temperature differences between the moving object and the
background temperature in the detection area. So, if the object dose not move,
the detector can not detect it, and changing of the temperature differences may
affect the detector's detection range.
Additionally, since this product has directional characteristic it is difficult to detect
the target that is approaching the detector.
- 1 -
INSTALLATION INSTRUCTIONS
No.5909614-000-05 2503-06
1 YEAR WARRANTY
Celing Mount Bracket: CA-2C
Multi-Angle Wall Mount Bracket: CA-1W
Adjust ±45° (Holizontally)
Adjust 0° to -20° (Vertically downwards)
Aim the detected at wall or the
ground, to avoid unwanted detection.
35 40 45 50 55 60 65 70 75
35 40 45 50 55 60 65 70 75
35 40 45 50 55 60 65 70 75
ft.
80
ft.
5
0
5 ft
m
ft.
80
ft.
8.3
5
m
ft.
80
ft.
8.3
5
m
