GPS Antenna
Manufacturer:
Description:
Model Number:
MultiTech Ordering Part Numbers
Model
ANGPS-1MM
ANGPS-10MM
ANGPS-50MM
Specifications
Category
Frequency Range
Impedance
VSWR
Gain
LNA Current Consumption
Noise Figure
Polarization
Input voltage
Placing GPS Antennas
GPS antennas need a clear view of the sky. Position the GPS antenna so the diversity antennas do not block its
view of the sky.
OEM Integration
FCC & IC Information to Consumers
The user manual for the consumer must contain the statements required by the following FCC and IC regulations:
47 C.F.R. 15.19(a)(3), 15.21, 15.105 and RSS-Gen Issue 3, Dec 2010; 7.1.2 and 7.1.3
FCC Grant Notes
The OEM should follow all the grant notes listed below. Otherwise, further testing and device approvals may be
necessary.
FCC Definitions
Portable: (§2.1093) — A portable device is defined as a transmitting device designed to be used so that the
radiating structure(s) of the device is/are within 20 centimeters of the body of the user.
®
SocketModem Cell MTSMC-Lxx Device Guide
Trimble
GPS Antenna with low noise amplifier
66800-52
Description
1575.24 MHz
50 Ohms
2.0:1 max
10-30 dBi
40 mA max
< 2dB
RHCP
3.0V M M 0.2V
Quantity
1
10
50
ANTENNAS
