ANTENNAS
LTE Antenna Specifications
Category
Frequency Range
Impedance
VSWR
Typical Radiated Gain
Radiation
Polarization
Cellular Antenna
Cellular devices were approved with the following antenna:
Manufacturer:
Description:
Model Number:
MultiTech ordering information:
Model
ANLTE2-2HRA
ANLTE2-10HRA
ANLTE2-50HRA
Cellular Antenna Specifications
Category
Frequency Range
Impedance
VSWR
Peak Gain
24
Description
698-806 MHz
824-894 MHz
880-960 MHz
1710-1880 MHz
1850-1990 MHz
1920-2170 MHz
2100-2500 MHz
2500-2690 MHz
50 Ohms
< 2.5:1
Low band
High band
Omni-directional
Linear
Wieson
LTE GY115HT467-017
11320Y11194A1
Quantity
1
10
50
Description
.069~0.96GHz, 1.71~2.17GHz, 2.3GHz~2.69GHz
50 Ohms
VSWR should not exceed 3:1 at any point across the bands of operation
3.8 dBi
0.5 dBi (698-960 MHz)
2.2 dBi (1710-2700 MHz)
