Goodwe Lynx Home F G2 Manual

The information in this quick guide is subject to change due to product updates or other reasons.
This guide cannot replace the product labels or the safety precautions in the user manual unless
otherwise specified. All descriptions in the manual are for guidance only.
01 Networking
Device Model
GW3600-EH, GW3600N-EH, GW5000-EH,
GW5000N-EH, GW6000-EH, GW6000N-EH,
Inverter
GW5000N-EH-BE, GW5000-EH-BE, GW3k-BH,
GW3600-BH, GW5000-BH, GW6000-BH
EH/BH 3-6kW Residential Smart Inverter Solutions Guide
Warning
Description
The inverter does not support parallel
use.
Device Model
Lynx Home F
Lynx Home F G2
Lynx Home F
LX F6.4-H-20
Plus+
Battery LX F9.6-H-20
LX F6.6-H
System LX F12.8-H-20
LX F9.8-H
LX F16.0-H-20
LX F13.1-H
LX F19.2-H-20
• GM3000
Smart
• GM1000
Meter
• GM1000D
• WiFi KIT
• WiFi+LAN KIT
Smart • 4G KIT-EC (Only for Europe)
Dongle • 4G KIT-AU (Only for Australia)
• BLUETOOTH KIT
• WiFi/LAN Kit-20
02 Power On/Off
❶→❷→❸→❹→❺
Power On/Off:
❸
: Install or not based on local laws and regulations
V1.0-2025-01-20
Description
Lynx
Home D
• A maximum of 8 battery systems
LX D5.0-10
can be clustered in a system.
• Do not mix battery systems of dif-
ferent versions.
• CT cannot be changed
• CT ratio: 120A/40mA
The inverter software version require-
ments for using smart dongles are as
follows:
• WiFi+LAN KIT: ARM version of in-
verters: 25 or above
• 4G KIT-EC and 4G KIT-AU: ARM ver-
sion of inverters: 20 or above
• BLUETOOTH KIT: ARM version of
inverters: 12 or above
• WiFi/LAN Kit-20: ARM version of
inverters: 30 or above
.
1
