  • Page 1 User Manual Rechargeable Li-ion Battery System Lynx Home D Series V1.0-2023-11-30...
  • Page 2 Copyright © GoodWe Technologies Co.,Ltd. 2023. All rights reserved. No part of this manual can be reproduced or transmitted to the public platform in any form or by any means without the prior written authorization of GoodWe Technologies Co.,Ltd. Trademarks and other GoodWe trademarks are trademarks of GoodWe Technologies Co.,Ltd.

  • Page 3: Table Of Contents

    CONTENT User Manual V1.0-2023-11-30 CONTENT 1 About This Manual ............... 01 1.1 Applicable Model ..................01 1.2 Target Audience ..................01 1.3 Symbol Definition ..................01 2 Safety Precaution ................. 02 2.1 General Safety ..................... 02 2.2 Battery Safety ....................03 2.3 Emergency Measures .................
  • Page 4 CONTENT User Manual V1.0-2023-11-30 7 System Operation ................ 32 7.1 Check Before Power On ................32 7.2 Battery System Power On ................32 7.3 Setting Battery Parameters ............... 34 7.4 Indicator Status ................... 36 8 Maintenance ................. 37 8.1 Battery System Power Off ................37 8.2 Routine Maintenance .................

  • Page 5: About This Manual

    All the installers and users have to be familiar with the product features, functions, and safety precautions. This manual is subject to update without notice. For more product details and latest documents, visit https://en.goodwe.com. 1.1 Applicable Model This manual applies to products with models LX D5.0-10.

  • Page 6: Safety Precaution

    • Strictly follow the installation, operation, and configuration instructions in this guide and user manual. The manufacturer shall not be liable for equipment damage personal injury if you do not follow the instructions. For more warranty details, please visit https:// en.goodwe.com/warranty.

  • Page 7: Battery Safety

    02 Safety Precaution User Manual V1.0-2023-11-30 2.2 Battery Safety DANGER • High voltage exists during the battery system running. Power off the battery system before any operations to avoid danger. Strictly follow all safety precautions outlined in this manual and safety labels on the equipment during the operation. •...

  • Page 8: Label Description

    02 Safety Precaution User Manual V1.0-2023-11-30 Label Description Potential risks exist. Wear proper Install the equipment away personnel protective equipment from open flames or fire before any operations. sources. High voltage hazard. High voltage exists when the equipment is Keep the equipment away running.

  • Page 9: Emergency Measures

    • The fire cannot be put out by water or ABC dry powder extinguisher. Firefighters are required to wear full protective clothing and self-contained breathing apparatus. 2.4 EU Declaration of Conformity GoodWe Technologies Co., Ltd. hereby declares that the inverter without wireless communication modules sold in the European market meets the requirements of the following directives: •...

  • Page 10: Product Introduction

    This manual applies to the listed battery below: • LX D5.0-10 Model Description Referring to Description Lynx Home D series Series code Usable energy 5.0: the usable energy of the battery system is 5.0kWh. Version code 10: version of the battery system is 1.0.
  • Page 11 03 Product Introduction User Manual V1.0-2023-11-30 Usable energy description NOTICE • The battery system supports capacity expansion. A maximum of 2 groups of batteries (up to 4 battery modules per group) and a total of 8 battery modules can be used to extend the usable energy of the battery system.

  • Page 12: Application Scenarios

    AC breaker meter grid BACK-UP Battery switch AC breaker Load breaker (Optional) Loads BACK-UP loads Battery system Approved inverter list Scan the QR code below or visit the official website to get the Approved Battery Options Statement. GoodWe Inverter GE Inverter...

  • Page 13: Appearance

    03 Product Introduction User Manual V1.0-2023-11-30 3.3 Appearance Parts Front View Left View Right View...
  • Page 14 03 Product Introduction User Manual V1.0-2023-11-30 Parts Description Battery SOC indicator light • SOC indicator light: Displays the battery SOC status. • Multi-function button indicator • Black start function: When there is no PV generating electricity in the PV system and the power grid is abnormal, if the inverter cannot work properly, you can press and hold the multi-functional button for 2 seconds to start...
  • Page 15 03 Product Introduction User Manual V1.0-2023-11-30 Dimensions 170mm 700mm 380mm Battery group dimensions (ground Battery group dimensions (wall-mount installation) installation) Base Wall mount rack...

  • Page 16: Check And Storage

    04 Check and Storage User Manual V1.0-2023-11-30 4 Check and Storage 4.1 Check Before Receiving Check the following items before receiving the product. 1. Check the outer packing box for damage, such as holes, cracks, deformation, and other signs of equipment damage. Do not unpack the contents from the box and contact the supplier as soon as possible if any damage is found.
  • Page 17 04 Check and Storage User Manual V1.0-2023-11-30 (Optional) base Base x 1 M5 screws x 2 M6 expansion Fixing bracket PE terminal bolts x 2 between base and battery x 2 Power connection Document Terminal Power connection Power connection terminal tighten- terminal x 2 resistor x 1 terminal x 2...

  • Page 18: Storage

    04 Check and Storage User Manual V1.0-2023-11-30 4.3 Storage If the equipment is not to be installed or used immediately, please ensure that the storage environment meets the following requirements: 1. Do not unpack the outer package or throw the desiccant away. 2.

  • Page 19: Installation

    05 System Installation User Manual V1.0-2023-11-30 5 Installation 5.1 Installation Requirements Installation Environment Requirements 1. Do not install the equipment in a place near flammable, explosive, or corrosive materials. 2. Do not install the equipment in a place that is easy to touch, especially within children’s reach. High temperature exists when the equipment is working.
  • Page 20 05 System Installation User Manual V1.0-2023-11-30 Keep the equipment away from children. 300mm 300mm 300mm 300mm-600mm 300mm 300mm ALT: 4000m IP66 0%~95%RH...

  • Page 21: Moving The Equipment

    05 System Installation User Manual V1.0-2023-11-30 Mounting Support Requirements • The mounting support shall be nonflammable and fireproof. • Install the equipment on a surface that is solid enough to bear its weight. • Put the battery system near the wall and install the locking brackets to prevent the battery from falling down.

  • Page 22: Installing The Battery System

    05 System Installation User Manual V1.0-2023-11-30 5.3 Installing the Battery System NOTICE • The battery system can be installed on a base or on a wall mount rack. • When stacking batteries, auxiliary tools need to be used for installation. •...

  • Page 23: Installing The Base (Optional)

    05 System Installation User Manual V1.0-2023-11-30 5.3.2 Installing the Base (Optional) Step 1: Place the base 5-20mm away from the wall, parallel to the wall, and ensure that the ground is level. level bar 5-20mm 5.3.3 Installing the Battery System Step 1: Fix the locking bracket onto the battery.
  • Page 24 05 System Installation User Manual V1.0-2023-11-30 D: 60mm Φ: 8mm L: 8mm 5-20mm 5N·m 5N·m...
  • Page 25 05 System Installation User Manual V1.0-2023-11-30 Ground installation 2N·m Wall mount installation 2N·m...

  • Page 26: Electrical Connection

    06 Electrical Connection User Manual V1.0-2023-11-30 6 Electrical Connection 6.1 Safety Precaution DANGER • High voltage exists during the battery system running. Power off the battery system before any operations to avoid danger. Strictly follow all safety precautions outlined in this manual and safety labels on the equipment during the operation.

  • Page 27: Electrical Connection

    06 Electrical Connection User Manual V1.0-2023-11-30 6.2 Electrical Connection Cable Connection for Single Group of Battery NOTICE • A single group of battery system can stack up to 4 batteries. • The communication port functions of the battery are consistent. Please ensure that one communication port of Battery 1 is connected to the inverter, and the other communica- tion port is connected to other battery.
  • Page 28 06 Electrical Connection User Manual V1.0-2023-11-30 Cable Connection for Single Group of Battery NOTICE • The battery system supports up to two groups of 8 batteries for capacity expansion. • The communication port functions of the battery are consistent. Please ensure that one communication port of Battery 1 is connected to the inverter, and the other communica- tion port is connected other battery.

  • Page 29: Connecting The Pe Cable

    06 Electrical Connection User Manual V1.0-2023-11-30 6.3 Connecting the PE Cable NOTICE • Connect the PE cable first before installing the equipment. Disconnect the PE cable before dismantling the equipment. • Make sure that the drawing force of the cable after crimping is greater than 400N. •...

  • Page 30: Connecting The Dc Power Cable

    06 Electrical Connection User Manual V1.0-2023-11-30 6.4 Connecting the DC power cable WARNING • The DC power cable should be prepared by the customer. Recommended specifications: • Type: single-core outdoor copper cable • Conductor cross-sectional area: 8mm ≤S﹤13.5mm • It is recommended to use YQK-70 hydraulic plier for crimping the DC terminals of batteries. When the cross-sectional area of the conductor is greater than or equal to 8mm less than 10mm , considering the thickness of the terminal wall, a crimping die that is...
  • Page 31 06 Electrical Connection User Manual V1.0-2023-11-30 If you need to remove the power connector, please refer to the following steps and use the tools delivered with the box. Connecting power cables Connecting power cables between a group of batteries...
  • Page 32 06 Electrical Connection User Manual V1.0-2023-11-30 Connecting power cables between two groups of batteries Connecting power cables between battery and inverter Inverter...

  • Page 33: Connecting The Communication Cable

    06 Electrical Connection User Manual V1.0-2023-11-30 6.5 Connecting the Communication Cable WARNING • The communication cable needs to be provided by customer. Recommended specifications: standard direct network cable and RJ45 connector. • If the matching inverter model has been equipped with a communication cable between the inverter and the battery at the factory, it can be determined whether to use the provided cable based on the actual situation.

  • Page 34: Installing The Terminal Resistor

    06 Electrical Connection User Manual V1.0-2023-11-30 6.6 Installing the Terminal Resistor WARNING • If the terminal resistor is not installed, it may cause the battery system not to work properly. • Do not remove the waterproof plug during installation.

  • Page 35: Installing Protective Cover

    07 Equipment Commissioning User Manual V1.0-2023-11-30 6.7 Installing Protective Cover NOTICE Before installing the front protective cover of the rack, please remove the release paper on the back of the protective cover. For ground installation only: If no cable pass through the base, install a hole plug here.

  • Page 36: System Operation

    07 Equipment Commissioning User Manual V1.0-2023-11-30 7 System Operation 7.1 Check Before Power On Check the following items before power on to avoid the battery system being damaged. Check Item The product is firmly installed at a clean place that is well-ventilated and easy-to operate.
  • Page 37 07 Equipment Commissioning User Manual V1.0-2023-11-30 Power ON Turn on: Turn on the breaker between the inverter and the battery system. Turn the battery power switch to the ON position and short press the battery multi-functional button. All batteries need to be powered on separately. Power on the inverter in the energy storage system.

  • Page 38: Setting Battery Parameters

    07 Equipment Commissioning User Manual V1.0-2023-11-30 7.3 Setting Battery Parameters NOTICE To ensure the normal operation of the battery system, after the battery system is powered on, the user needs to select correct battery model through the SolarGo App. Step 1: Download the SolarGo App. play <5m SolarGo...
  • Page 39 • Incorrect battery model may cause system failure. Please set the battery model correctly. • If only one battery is used, please select "Lynx Home D Series"; If multiple batteries are used, please select "Lynx Home D Series * N".

  • Page 40: Indicator Status

    07 Equipment Commissioning User Manual V1.0-2023-11-30 7.4 Indicator Status Normal status SOC indicator status Button indicator Battery system status status SOC indicator indicates SOC of the Green light blinks The battery system is in standby battery system. status. SOC﹤5% 5%≤SOC﹤25% The battery system is in 25%≤SOC﹤50% charging status.

  • Page 41: Maintenance

    08 Maintenance User Manual V1.0-2023-11-30 8 Maintenance 8.1 Battery System Power Off DANGER • Power off the battery system before operations and maintenance. Otherwise, the equipment may be damaged or electric shocks may occur. • Strictly follow the power off requirements to avoid damaging the system. (Optional) Battery Group 2 Battery group 1...

  • Page 42: Routine Maintenance

    08 Maintenance User Manual V1.0-2023-11-30 8.2 Routine Maintenance WARNING • Contact the after-sales service for help if you find any problems that may influence the battery or the hybrid inverter. Disassemble without permission is strictly forbidden. • Contact after-sale service for help if the copper conductor is exposed. Do not touch or disassemble privately because the high voltage danger exists.

  • Page 43: System Troubleshooting

    08 Maintenance User Manual V1.0-2023-11-30 8.4 System Troubleshooting The battery system may power off automatically and some functions may not work properly once the battery system fails. Perform troubleshooting according to the following methods. Contact the after-sales service if these methods do not work. Collect the information below before contacting the after-sales service, so that the problems can be solved quickly.
  • Page 44 08 Maintenance User Manual V1.0-2023-11-30 Overcurrent Restart the battery. Contact the after- Discharging sale service if the problem persists. Red light steady Temperature Power off and wait for 2 hours. Difference Excep- Contact the after-sale service if the Red light steady tion problem persists.
  • Page 45 08 Maintenance User Manual V1.0-2023-11-30 Restart the battery. Contact the after- Precharge Failure sale service if the problem persists. Red light steady MOS over Power off and wait for 2 hours. temperature Contact the after-sale service if the Red light steady fault problem persists.

  • Page 46: Technical Parameters

    09 Technical Parameters User Manual V1.0-2023-11-30 9 Technical Parameters Technical Parameters LX D5.0-10 Usable energy (kWh)* Cell Type LFP (LiFePO4) Cell Configuration 16S1P Nominal Voltage (V) Charge:435V; Discharge 380V Operating Voltage Range (V) 320~480V Nominal Charge/Discharge Power (kW) Peak Power 5KW,10s Operating Temperature Range Charge: 0~+53;...
