User Manual
PT-SP-HD18-48G
5. System Diagram
Usage Precaution
⚫
Make sure all components and accessories included before installation.
⚫
System should be installed in a clean environment with proper
temperature and humidity.
⚫
All of the power switches, plugs, sockets, and power cords should be
insulated and safe.
⚫
All devices should be connected before power on.
The following diagrams illustrate typical input and output connections that
can be utilized with this device:
8K TV 1
IN
DVD or Blu-ray Player
The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo
are trademarks or registered trademarks of HDMI Licensing LLC in the United States and
other countries.
OUT 1
OUT 2
OUT 3
OUT 4
8K TV 8
OUT 5
OUT 6
OUT 7
OUT 8
AVR or Amplifier
10
Power Supply
OPTICAL
L/R
DC 12V
Line Level
Audio Device
