- Page 1 Horizon Elite Ice Machine Installation Instructions ™ for Ice Storage Bin Top-mount Applications D1010R, D1410R, D1412R, D1810R, D2110R remote condensing 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01565068R00 www.follettice.com...
- Page 2 CAUTION! • This appliance should be connected by a qualified person in accordance with applicable codes. • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. •...
- Page 3 Read and complete the following 8 installation steps Unpack Site preparation Bin preparation Docking assembly Ice transport tube External connection Internal connection Front cover BIN • TOP-MOUNT remote condensing...
- Page 4 Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack ice machine ➋ ➌ ➊ ➎ ➍ 7/16" DO NOT TILT ICE MACHINE TO ACCESS BOLTS! COMPRESSOR DAMAGE 7/16" WILL RESULT ➐ ➏ BIN • TOP-MOUNT remote condensing...
-
Page 5: Site Preparation
Site preparation Prepare the installation site. Provide drainage, water supply and electrical power to within 6 feet (2m) of ice machine in accordance with local and national codes. Outdoor installation is not recommended and will void warranty. Installation site requirements ➌... - Page 6 Bin preparation Prepare the bin. Bin top preparation Bin top preparation — – ˜ – • Remove protective tape from ➊ • Apply gaskets gaskets ➋ • Install shuttle actuator through bin top and secure with locking nut ➌ BEFORE PROCEEDING Prior to installing the docking assembly, ensure that the drain fitting is oriented (right or left) correctly for your installation.
- Page 7 Docking assembly Install the docking assembly. Docking assembly 2" (50,8 mm) 1.88" (47,8 mm) ➋ ➊ 3/8˝ ∅ 1" (25,4 mm) high pressure Stub Typ line 3.38" (86 mm) ➊ 1010/1410: 5/8" ∅ low pressure line 1412/1810/2110: 7/8" ∅ low pressure line •...
-
Page 8: Ice Transport Tube
Ice transport tube Install the ice transport tube. ➋ Hot Water 160 F (71 C) ➊ ➌ • Slide insulation onto ice transport tube • Heat end of transport tube in cup of 160 F (71 C) hot water to soften and spread with pliers ➊... -
Page 9: External Connections
External connections Connect utilities to docking assembly. Water and flush drain ➊ Chassis drain plumbing - required ➋ ➌ Minimum 8" ➏ radius 2 ft. x 1" OD silicone tubing • Plug must be removed from John Guest 3/4" barb x 3/4" FPT fitting. -
Page 10: Internal Connections
Internal connections Connect docking assembly to ice machine. Water solenoid, shut-off valve, Ice transport tube installation and potable water line options If water solenoid is already mounted to evaporator: • Insert potable water line into shut-off valve. If this is an undercounter installation: •... - Page 11 Power cord TDS switch HIGH CLEAN • Position plate into opening and secure • Set the TDS switch on the electrical box: with supplied screw HIGH: for extended service life LOW: for low-scale water BIN • TOP-MOUNT remote condensing...
-
Page 12: Front Cover
Ice machine MUST be sanitized prior to operation! Consult Operation and Service Manual provided with ice machine for sanitizing instructions. Maestro, Vision, Ice Manager, Horizon Elite are trademarks of Follett Products, LLC. Chewblet, RIDE, Follett are registered trademarks of Follett Products, LLC.
