Ice Machine Installation Instructions
self-contained
00978767R01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Horizon H C700ABT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Follett Horizon H C700ABT

  • Page 1 ™ Horizon Ice Machine Installation Instructions to Ice Storage Bin Top-mount Applications H_C700ABT, H_C700WBT, H_D700ABT, H_D700WBT, H_E700ABT, H_E700WBT, (See model number confi gurator on page 2 for details.) self-contained Order parts online www.follettice.com 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 •...
  • Page 2 Chewblet ® Ice Machine Model Number Configurations Machine Voltage Series Condenser Application Configuration ® MC Maestro™ C 208-230/60/1 (icemaking head) 400 up to Air-cooled, self-contained V Vision™ S RIDE Self-contained only. 454 lbs Chewblet W Water-cooled, H Harmony™ (RIDE remote ice D 115/60/1 (icemaking head) (206kg) (400 Series)
  • Page 3 Read and complete the following 8 installation steps Unpack Site preparation Dispenser preparation Louvered docking assembly Ice transport tube External connection Internal connection Front cover BIN • TOP-MOUNT self-contained...
  • Page 4 Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack ice machine 7/16" 7/16" BIN • TOP-MOUNT self-contained...
  • Page 5: Site Preparation

    Site preparation Prepare the installation site. Provide drainage, potable water supply and electrical power to within 6 feet (2m) of ice machine in accordance with local and national codes. Outdoor installation is not recommended and will void warranty. Installation site requirements H_D700A/W NEMA 5-15...
  • Page 6 Bin preparation Prepare the bin. Bin top preparation Bin top preparation ➋ ➊ ➌ ➊ • Remove protective tape from gaskets ➊ • Apply gaskets ➋ • Install shuttle actuator through dispenser top and secure with locking nut ➌ BIN • TOP-MOUNT self-contained...
  • Page 7 Louvered docking assembly Install the louvered docking assembly. WARNING! • Docking station must be secured in accordance with these instructions to ensure ice machine stability. • Ventilation openings in the louvered docking station should be clear of obstruction. Failure to do so could result in damage to equipment.
  • Page 8: Ice Transport Tube

    Ice transport tube Install the ice transport tube. Ice transport tube installation. Hot Water 160 F (71 C) • Cut transport tube to 26” (66 cm) length • Install supplied ice transport tube insulation ➊ • Heat end of transport tube in cup of 160 F (71 C) hot water to soften and spread with pliers before making connection to ease assembly ➋...
  • Page 9: External Connections

    External connections Connect utilities to louvered docking assembly. Air-cooled icemakers only Water-cooled icemakers only ➋ ➍ ➋ ➌ ➊ ➊ • Remove access panel if necessary • Remove access panel if necessary ➊ ➊. • Install drain line • Install drain line The rigid drain line from the ice machine The rigid drain line from the ice machine must be vented and have at least 1/4”...
  • Page 10: Internal Connections

    Internal connections Connect ice machine to louvered docking assembly. CAUTION! • Plug must be accessible after fi nal installation. Air-cooled ice machines – follow steps 7.1 through 7.4. Ice transport tube Potable water and drain lines ➋ ➊ • Slide ice machine into louvered docking ➊...
  • Page 11 Water-cooled ice machines – follow steps 7.5 through 7.10. Cooling lines Ice transport tube ➋ ➊ • Slide ice machine into louvered docking ➊ • Install ice machine cooling water lines to assembly louvered docking assembly • Insert ice transport tube into coupling and ➋...
  • Page 12 WARNING! • This appliance should be permanently connected by a qualifi ed person in accordance with application codes. • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualifi ed persons in order to avoid a hazard.
  • Page 13 BIN • TOP-MOUNT self-contained...
  • Page 14: Front Cover

    Front cover Install front cover to ice machine. Install front cover • Slide ice machine cover over machine, ensuring that tabs on back of cover slip under louvers on back of louvered ➊, docking assembly then tighten two screws through cover ➋...
  • Page 15 BIN • TOP-MOUNT self-contained...
