Welcome to Follett
Follett equipment enjoys a well-deserved reputation for excellent performance, long-term reliability and outstanding
after-the-sale support. To ensure that this equipment delivers that same degree of service, review this guide
carefully before you begin your installation.
Should you need technical help, please call our Technical Service group at (877) 612-5086 or (610) 252-7301.
Please have your model number, serial number and complete and detailed explanation of the problem when
contacting Technical Service.
Getting Started
After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. All freight
is to be inspected upon delivery. If visible signs of damage exist, please refuse delivery or sign your delivery receipt
"damaged." Follett Customer Service must be notified within 48 hours. Wherever possible, please include detailed
photos of the damage with the original packaging so that we may start the freight claim process.
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
Horizon Elite 1412 Ice Machines (Remote Condensing)
www.follettice.com
Horizon Elite™ D1412R Ice Machines
D1412R
(Remote Condensing)
After Serial Number R03746
Please visit www.follettice.com/technicaldocuments
for the Operation and Service manual for your unit.
User Guide
Installation and Service Videos:
www.follettice.com/servicevideolibrary
01519115R02
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Follett Horizon Elite D1412
Summary of Contents for Follett Horizon Elite D1412
- Page 1 If visible signs of damage exist, please refuse delivery or sign your delivery receipt "damaged." Follett Customer Service must be notified within 48 hours. Wherever possible, please include detailed photos of the damage with the original packaging so that we may start the freight claim process.
-
Page 2: Specifications
§ Ice is food. Follow recommended cleaning instructions to maintain cleanliness of delivered ice. § Follett recommends a Follett water filter system be installed in the ice machine inlet water line (standard capacity #01556596, high capacity #01556620, carbonless high capacity #01556646). - Page 3 Flush drain plumbing § Apply Teflon tape to 3/4" male outlet ice machine fitting. Thread on either the provided straight 3/4" barb adapter or a 90 degree adaptor. Connect the supplied 2' (0.61 m) silicone hose to the 3/4" drain barb. § It is recommended that the silicone hose be routed down into a 1.5" or 2" standpipe/drain. The minimum drain size for the ice machine is 1".
- Page 4 Water Solenoid and Shut-off Valve Standard Installations Mount water solenoid to inside rear of docking assembly using one screw ➊ , insert potable water line into valve ➋ ➌ ,insert tubing into push-in connection of water solenoid ➋ ➌ ➊ Mount water solenoid ATTENTION INSTALLER!
-
Page 5: Ice Production
Ambient Evaporator unit Air temperature 100 F/38 C max. 50 F/10 C min. Water temperature 90 F/32 C max. 45 F/7 C min. Water pressure 70 psi max. (483 kPa) 10 psi min. (69 kPa) Condenser unit Air temperature 120 F/49 C max. –20F/–29C min. -
Page 6: Dimensions And Clearances
Dimensions and clearances § Entire front of ice machine must be clear of obstructions/connections to allow removal. § 1" (26 mm) clearance above ice machine for service. § 1" (26 mm) minimum clearance on sides. § The intake and exhaust air grilles must provide at least 250 sq in (1615 sq cm) of open area. §... - Page 7 Condensing unit – F1412CU 1412 three phase Horizon Elite 1412 series – F1412CU W1 Width 39.6” (100.6 cm) D1 Depth 28.2” (71.6 cm) H1 Height 26.0” (66.0 cm) Electrical three phase – 208-230/60/3 (Emerson/Copeland) Minimum circuit ampacity three phase – 12A Maximum overcurrent protection three phase –...
-
Page 8: Operation
Do not use bleach to sanitize or clean the icemaker. Preventive maintenance Periodic cleaning of Follett’s icemaker system is required to ensure peak performance and delivery of clean, sanitary ice. The recommended cleaning procedures that follow should be performed at least as frequently as recommended, and more often if environmental conditions dictate. - Page 9 Fig. 2 2. Follow the directions on the SafeCLEAN Plus packaging to mix 1 gal. (3.8 L) of Follett SafeCLEAN Plus solution. Use 120 F (49 C) water. 3. Using a 1 quart (1 L) container, slowly fill cleaning cup until CLEANER FULL light comes on and cleaner just begins to flow from the vent tube.
- Page 10 Fig. 5 7. Disconnect coupling as shown. Fig. 6 8. Using disposable foodservice grade gloves, insert both SaniSponge cleaning sponges saturated in SafeClean Plus (from Step 4). 9. Push both SaniSponge cleaning sponges down ice transport tube with supplied pusher tube. Fig.
- Page 11 Fig. 8 11. Reconnect coupling. Press power switch ON. Ice pushes SaniSponge cleaning sponges through ice transport tube. Fig. 9 12. Place a sanitary (2 gal. or larger) container in bin or dispenser to collect SaniSponge cleaning sponges and ice for 10 minutes after the Sani-Sponges come out.
- Page 12 Wiring diagram, evaporator unit Gearmotor data Resistance of windings 115 vac gearmotor (Brother): Gearmotor current Bison 2.8A @ 115 V Brother 4.0 @ 115 V White to Black: 3Ω White to Red: 3Ω Gearmotor torque-out (high amp) trip point: 5.6A Red to Black: 6Ω...
- Page 13 1412 Three-phase condensing unit wiring diagram 3-PHASE, 208-230 VAC F1412CU OUTDOOR CONDENSING UNIT ICE MAKER DISCH DOCKING SIGNAL, FIELD SIDE HIGH DISCH STATION WIRED,CLASS 2 RELAY PRESS SW T-STAT BLK H1 10 RED 16AWG TB2-1, TB2-2 CRANKCASE 11 BLK 16AWG HEATER BLK H2 1 2 3 4 5 6...
-
Page 14: Refrigeration System
Refrigeration system Air-cooled condensers (air) 50 F/ 60 F/ 70 F/ 80 F/ 90 F/ 100 F/ 110 F/ 120 F/ 10 C 16 C 21 C 27 C 32 C 38 C 43 C 49 C Pressure (psig) discharge/ 182/18 186/19 190/20... -
Page 15: Refrigeration Charge
Note: Condensing unit shipped with full charge. Refrigerant replacement requirements 1. Non-contaminated refrigerant removed from any Follett refrigeration system can be recycled and returned to the same system after completing repairs. Recycled refrigerant must be stored in a clean, approved storage container. - Page 16 Ice capacity test Ice machine production capacity can only be determined by weighing ice produced in a specific time period. 1. Replace all panels on ice machine. 2. Run ice machine for at least 15 minutes. 3. Move TDS switch to LOW. 4.
- Page 17 Condenser installation specifications ➍ Low voltage control (24 Vac) required CONDENSER UNIT 100' max. ➍ (30.5 m) maximum ➊ line rise P-trap ➋ required S-trap required ➊ +35' (+10.7 m) +20' (+6.1 m) P-trap required Easton Pennsylvania MODEL CORPORATION SERIAL NO PART NO FULL LOAD AMPS VOLTS...
-
Page 18: Troubleshooting
Troubleshooting Ice machine disposition Possible causes Corrective action Legend: ON or OFF FLASHING Machine in TIME DELAY without full 1. Ice jamming due to improperly 1. Correct transport tube routing. bin. installed transport tube causing a false 2. Repair or replace shuttle mechanism. shuttle. - Page 19 Warranty Registration and Equipment Evaluation Thank you for purchasing Follett Products, LLC equipment. Our goal is to earn your complete satisfaction by delivering high- value products and services backed by outstanding customer and technical support. Please review the installation instructions thoroughly. It is important that the installation be performed to factory specifications so your equipment operates at its maximum efficiency.
- Page 20 Horizon Elite, SafeCLEAN Plus, and SaniSponge are trademarks of Follett Products, LLC. Follett is a registered trademark of Follett Products, LLC, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01519115R02 www.follettice.com...
