- Page 1 Countertop and Freestanding Ice and Water Dispenser with Chewblet Ice Icemaker ® 7CI100A, 7FS100A Installation, Operation and Service Manual Serial numbers D17617 to D25455 7CI100A 7FS100A Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • Easton, PA 18040, USA Order parts online: Toll free (877) 612-5086 •...
-
Page 2: Table Of Contents
Contents –––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Before You Begin . -
Page 3: Welcome
After uncrating and removing all packing material, inspect the equipment for concealed shipping damage . If damage is found, immediately notify the shipper and contact Follett Corporation so that we can help in the filing of a claim, if necessary . -
Page 4: Specifications
Specifications ––––––––––––––––––––––––––––––––––––––––––––––––––––– Dimensions 7CI100A 7FS100A Width 14 .55" (370 mm) 14 .55" (370 mm) Depth 22 .05" (560 mm) 22 .05" (560 mm) Height 17 .53" (450 mm) 41 .93" (1065 mm) Unit Shipping Weight 90 lb (41 kg) 120 lb (54 .4 kg) Ambient Information CAUTION! The 7CI100A and 7FS100A are for indoor use only. -
Page 5: Detailed Drawing
Specifications –––––––––––––––––––––––––––––––––––––––––––––– (continued) Detailed Drawing Countertop models 14.55" (370 mm) 14.55" (370 mm) NEMA 5-15 right angle 17.54" 17.54" (446 mm) (446 mm) 6.72" 6.79" (171 mm) (172 mm) power cord 22.05" (560 mm) 1/4" NPT 2.40" 2.98" (61 mm) (76 mm) water inlet Freestanding models... -
Page 6: Installation
Installation –––––––––––––––––––––––––––––––––––––––––––––––––––––––– CAUTION! No service or maintenance should be performed until the technician has thoroughly read this service manual. Except for routine cleaning and sanitizing, only qualified technicians should attempt to service or maintain this equipment. Countertop Installation Fig . 1 Installation instructions for freestanding model may be found on page countertop models... - Page 7 Installation ––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Optional Drip Tray Drain Installation Fig . 3 1 . If installing optional Drip Tray Drain Kit*, cut hole in countertop for drain tube . Units without legs must have alternate hole positioning (Fig . 3) * The optional Drip Tray Drain Kit (item# 00956375) requires a floor drain within 15 3/4"...
-
Page 8: Freestanding Installation
Installation ––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Optional Leg Accessory Installation Fig . 5 1 . If installing optional 4" Leg Accessory (item# 00956300), place a 5" (127 mm) spacer underneath the dispenser to ease installation . 2 . Remove four plastic, thread-protecting plugs from bottom of dispenser . - Page 9 Installation ––––––––––––––––––––––––––––––––––––––––––––––––– (continued) 3 . Remove four plastic, thread-protecting plugs from bottom of Fig . 7 dispenser . 4 . Attach dispenser to base stand with supplied hardware (Fig . 7) . NOTICE! If installing optional Drip Tray Drain Kit, complete those steps before proceeding.
- Page 10 Installation ––––––––––––––––––––––––––––––––––––––––––––––––– (continued) 8 . Secure unit to wall or cove molding with supplied bracket (Fig . 9) to Fig . 9 prevent tipping . Note: Fasteners must be supplied by installer . WARNING! Freestanding unit must be secured to wall to prevent tipping. Failure to do could result in personal injury or damage to the unit.
-
Page 11: Maintenance/Cleaning Mode
Maintenance/Cleaning Mode ––––––––––––––––––––––––––––––––––––––––– Cleaning Mode (Dispensing Disabled) - Use when cleaning surface Fig . 12 Entering Cleaning Mode disables the User Interface and allows you to clean the outside of the dispenser without accidentally dispensing water or ice . 1 . To enter Cleaning Mode, press and immediately release the maintenance/clean switch (Fig . -
Page 12: Filter Display Indicator Activation
Filter Display Indicator Activation ––––––––––––––––––––––––––––––––––––– Fig . 14 If you purchased your dispenser with a Follett filter, the filter display indicator activation has been preset at the factory . If you are using an “after market filter,” an adjustment may be made to activate the “Fresh Filtered Ice &... -
Page 13: Cleaning And Sanitizing
Cleaning and Sanitizing ––––––––––––––––––––––––––––––––––––––––––––– Fig . 16 Cleaning and sanitizing should be performed at least every 6 months, and more often if local water conditions dictate . CAUTION! Place the dispenser in Maintenance Mode prior to servicing or cleaning the ice machine. See Maintenance/Cleaning Mode on page Required Supplies... -
Page 14: Service
Internal leak in dispenser . High amps Auger gearmotor has exceeded 0 .55 amps . Service 8000 hour bushing check (call Follett technical service group at (877) 612-5086 or +1 (610) 252-7301) . Maintenance Yellow Enter Maintenance Mode by pressing and holding maintenance/clean switch for 5 seconds . -
Page 15: Water Feed Schematic
Service –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Water Feed Schematic Evaporator Float Water Chute (optional) Water Solenoid Valve Filter (optional) (optional) Water Solenoid Valve Dispenser and Icemaker 7CI100A/7FS100A... -
Page 16: Bin Melt Water/Evaporator Feed/Clean Out System Schematic
Service –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Bin Melt Water/Evaporator Feed/Clean Out System Schematic Storage Bin Vent System Schematic Storage Bin Vent Tube Reservoir Tube Dispenser and Icemaker 7CI100A/7FS100A... -
Page 17: Refrigeration Schematic
Service –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Refrigeration Schematic CONDENSER FILTER-DRIER CAP TUBE COMPRESSOR EVAPORATOR ACCUMULATOR LOW PRESSURE LIQUID HIGH PRESSURE VAPOR HIGH PRESSURE LIQUID LOW PRESSURE VAPOR Dispenser and Icemaker 7CI100A/7FS100A... -
Page 18: Condenser Fan Motor Removal
Service –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Condenser Fan Motor Removal Dispenser and Icemaker 7CI100A/7FS100A... -
Page 19: User Interface Display Identification
Service –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) User Interface Display Identification Condition Operation Display Procedure Normal — operation Cleaning Mode Press and release maintenance/clean switch to clean the user interface without dispensing ice or water (see Maintenance/Cleaning Mode on page 11). Drip tray full Empty drip tray . - Page 20 Contact Follett technical service group at (877) 612- 5086 or +1 (610) 252-7301) . Internal leak in dispenser Locate leak and repair - Press reset on control board . Contact Follett if icemaker is leaking . Dispenser and Icemaker 7CI100A/7FS100A...
-
Page 21: Electrical Wiring Diagram
Service –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Electrical Wiring Diagram Dispenser and Icemaker 7CI100A/7FS100A... -
Page 22: Parts
Parts ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Exterior Dispenser and Icemaker 7CI100A/7FS100A... - Page 23 Parts –––––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Exterior Reference # Description Part # Drain, Tray Assy 00957613 Panel, Front Assy - Includes Water Nozzle and Plug 00957621 Chute, Water 00957688 Panel, Left 00957639 Panel, Right 00957647 Panel, Top 00957654 Panel, Rear 00957662 Not Shown Cord, 115 VAC 00958058 Not Shown...
-
Page 24: Interior
Parts –––––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Interior Dispenser and Icemaker 7CI100A/7FS100A... - Page 25 Parts –––––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Interior Reference # Description Part # Valve, Dispense Solenoid 00957704 Switch, Cleaning 00957712 Drain/Feed Tube with Cap 00957720 Valve, Failsafe Solenoid 00957738 Compressor with Mounting Hardware 00958009 Condenser 00958017 Condenser Fan and Cord 00958025 Control Board with Stand-offs 00958033 Capacitor, Gearmotor 00958041...
-
Page 26: Bin Assembly
Parts –––––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Bin Assembly Dispenser and Icemaker 7CI100A/7FS100A... - Page 27 Parts –––––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Bin Assembly Reference # Description Part # Ice Chute Assembly 00957670 Ice Transport Tubing with Insulation 00957746 Switch, Shuttle 00957753 Shuttle, Complete Assembly 00957761 Lid, Bin Assembly 00957779 Bin, Assembly 00957787 Auger, Dispense 00957795 Motor, Dispense 00957803 Cap and Insulation, Bin 00957936 Not Shown...
-
Page 28: Evaporator Assembly
Parts –––––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Evaporator Assembly Dispenser and Icemaker 7CI100A/7FS100A... - Page 29 Parts –––––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Evaporator Assembly Reference # Description Part # Gearmotor 00957811 Main Housing with Front Seal and Screws 00957829 Screws, Main Housing 00957837 Auger with front seal 00957845 Ice Compression Nozzle Assembly 00957852 Front Seal and O-Ring 00957860 Evaporator Assembly with Insulation 00957878 Housing, Bushing with Insulation 00957886...
-
Page 30: Base Stand
Parts –––––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Base Stand Dispenser and Icemaker 7CI100A/7FS100A... - Page 31 Parts –––––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Base Stand Reference # Description Part # Front Panel, Base 00958108 Latches with Bayonets, Base 00958116 Not Shown Tray, Base 00958124 Not Shown Packaging for Returns, Base 00957985 Dispenser and Icemaker 7CI100A/7FS100A...
- Page 32 SafeCLEAN and SensorSAFE are trademarks of Follett Corporation. Chewblet and Follett are registered trademarks, and Horizon is a trademark of Follett Corporation, registered in US. 801 Church Lane • Easton, PA 18040, USA 00951640R02 Toll free (877) 612-5086 • +1 (610) 252-7301 04/11 www.follettice.com...
