Welcome to Follett
Follett equipment enjoys a well-deserved reputation for excellent performance, long-term reliability and outstanding
after-the-sale support. To ensure that this equipment delivers that same degree of service, review this guide
carefully before you begin your installation.
Should you need technical help, please call our Technical Service group at (877) 612-5086 or (610) 252-7301.
Please have your model number, serial number and complete and detailed explanation of the problem when
contacting Technical Service.
Getting Started
After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. All freight
is to be inspected upon delivery. If visible signs of damage exist, please refuse delivery or sign your delivery receipt
"damaged." Follett Customer Service must be notified within 48 hours. Wherever possible, please include detailed
photos of the damage with the original packaging so that we may start the freight claim process.
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
Horizon Elite D1010R/D1410R Ice Machines (Remote Condensing)
www.follettice.com
Horizon Elite™ D1010/D1410 Ice Machines
D1010R, D1410R
(Remote Condensing)
After Serial Number R03746
Please visit www.follettice.com/technicaldocuments
for the Operation and Service manual for your unit.
User Guide
Installation and Service Videos:
www.follettice.com/servicevideolibrary
01252592R08
1
Advertisement
Table of Contents
Related Manuals for Follett Horizon Elite D1010
Summary of Contents for Follett Horizon Elite D1010
- Page 1 If visible signs of damage exist, please refuse delivery or sign your delivery receipt "damaged." Follett Customer Service must be notified within 48 hours. Wherever possible, please include detailed photos of the damage with the original packaging so that we may start the freight claim process.
-
Page 2: Specifications
§ Ice is slippery. Maintain counters and floors around dispenser in a clean and ice-free condition. § Ice is food. Follow recommended cleaning instructions to maintain cleanliness of delivered ice. § Follett recommends a Follett water filter system be installed in the ice machine inlet water line (standard capacity, high capacity, carbonless high capacity). - Page 3 Evaporator plumbing § 3/8" OD push-in water inlet - 3/8" OD tubing required. § Water shut-off recommended within 10 feet (3 m). Flush drain plumbing § 3/4" MPT flush drain connection at the rear of the machine. § Drain must slope 1/4" per foot (6 mm per 30,4 cm). §...
-
Page 4: Ice Production
Ambient Evaporator unit Air temperature 100 F/38 C max. 50 F/10 C min. Water temperature 90 F/32 C max. 45 F/7 C min. Water pressure 70 psi max. (483 kPa) 10 psi min. (69 kPa) Condenser unit Air temperature 120 F/49 C max. –20F/–29C min. -
Page 5: Dimensions And Clearances
Dimensions and clearances § Entire front of ice machine must be clear of obstructions/connections to allow removal. § 1" (26 mm) clearance above ice machine for service. § 1" (26 mm) minimum clearance on sides. § The intake and exhaust air grilles must provide at least 250 sq in (1615 sq cm) of open area. §... - Page 6 Condensing unit 1010/1410 single phase (Tecumseh) 1410 three phase (Larkin) 1010 three phase (Tecumseh) Horizon Elite D1010CU Horizon Elite D1410CU W1 Width 39.9" (101.3 cm) – Model ASAFR9510ZNAMC1, 39.9" (101.3 cm) – Model ASFS9516ZNAMC1 37.75" (95,9 cm) – three phase (Larkin) ASFR9511ZFAMC1 36.25"...
-
Page 7: Operation
Cleaning of the condenser can usually be performed by facility personnel. Cleaning of the icemaker system, in most cases, should be performed by your facility’s maintenance staff or a Follett authorized service agent. Regardless of who performs the cleaning, it is the operator’s responsibility to see that this cleaning is performed according to the schedule below. - Page 8 Fig. 2 2. Follow the directions on the SafeCLEAN Plus packaging to mix 1 gal. (3.8 L) of Follett SafeCLEAN Plus solution. Use 120 F (49 C) water. 3. Using a 1 quart (1 L) container, slowly fill cleaning cup until CLEANER FULL light comes on and cleaner just begins to flow from the vent tube.
- Page 9 Fig. 5 7. Disconnect coupling as shown. Fig. 6 8. Using disposable foodservice grade gloves, insert both SaniSponge cleaning sponges saturated in SafeClean Plus (from Step 4). 9. Push both SaniSponge cleaning sponges down ice transport tube with supplied pusher tube. Fig.
- Page 10 Fig. 8 11. Reconnect coupling. Press power switch ON. Ice pushes SaniSponge cleaning sponges through ice transport tube. Fig. 9 12. Place a sanitary (2 gal. or larger) container in bin or dispenser to collect SaniSponge cleaning sponges and ice for 10 minutes after the Sani-Sponges come out.
- Page 11 Wiring diagram, evaporator unit Gearmotor data Resistance of windings 115 vac gearmotor (Brother): Gearmotor current Bison 2.8A @ 115 V Brother 4.0 @ 115 V White to Black: 3Ω White to Red: 3Ω Gearmotor torque-out (high amp) trip point: 5.6A Red to Black: 6Ω...
- Page 12 Models AJA7490ZXDPN, AWA9513ZXDPN Single-phase condensing unit wiring diagram (Tecumseh) FAN 1 FAN 2 COMPRESSOR CONTACTOR COIL see note A RECEIVER TERMINAL HEATER BOARD HEATER THERMOSTAT POWER SUPPLY 230-60-1 POTENTIAL RELAY see note B COMPRESSOR CONTACTOR NC AUXILIARY SWITCH CRANK CASE HEATER COMPRESSOR CONTACTOR...
- Page 13 Models ASAFR9510ZNAMC1, 1010 Single-phase condensing unit wiring diagram (Tecumseh) Horizon Elite D1010R/D1410R Ice Machines (Remote Condensing)
- Page 14 Models ASFS9516ZNAMC1, 1410 Single-phase condensing unit wiring diagram (Tecumseh) Horizon Elite D1010R/D1410R Ice Machines (Remote Condensing)
- Page 15 Model AWA9490ZXTPN 3-phase condensing unit wiring diagram (Tecumseh) FAN 1 FAN 2 TO "Y-OUT" TO "230 VAC" AT PHASE AT PHASE MONITOR MONITOR COMPRESSOR D.T. TO "C" CONTACTOR AT PHASE COIL see note A MONITOR RECEIVER TERMINAL TERMINAL HEATER BOARD BOARD HEATER THERMOSTAT...
- Page 16 Models ASFR9511ZFAMC1, 1010 3-phase condensing unit wiring diagram (Tecumseh) Horizon Elite D1010R/D1410R Ice Machines (Remote Condensing)
- Page 17 3-phase condensing unit wiring diagram (Larkin) Horizon Elite D1010R/D1410R Ice Machines (Remote Condensing)
-
Page 18: Refrigeration System
Refrigeration system D1010R - Refrigerant pressure data Air-cooled condensers (air) 60 F/16 C 70 F/21 C 80 F/27 C 90 F/32 C 100 F/38 C Pressure (psig) discharge/suction 202/33 229/35 255/37 275/38 295/39 D1410R - Refrigerant pressure data Air-cooled condensers (air) 60 F/16 C 70 F/21 C 80 F/27 C... -
Page 19: Refrigeration Charge
Note: Condensing unit shipped with 0.5 lb of R404A charge. Refrigerant replacement requirements 1. Non-contaminated refrigerant removed from any Follett refrigeration system can be recycled and returned to the same system after completing repairs. Recycled refrigerant must be stored in a clean, approved storage container. - Page 20 Ice capacity test Ice machine production capacity can only be determined by weighing ice produced in a specific time period. 1. Replace all panels on ice machine. 2. Run ice machine for at least 15 minutes. 3. Move TDS switch to LOW. 4.
- Page 21 Condenser installation specifications CONDENSER UNIT 100' max. ➍ (30.5 m) maximum ➊ line rise P-trap ➋ S-trap required required ➊ +35' (+10.7 m) +20' (+6.1 m) Easton Pennsylvania MODEL CORPORATION SERIAL NO PART NO FULL LOAD AMPS VOLTS PHASE SINGLE MOTOR COMPRESSOR THERMALLY PROTECTED REFRIGERANT CHARGE...
-
Page 22: Troubleshooting
Troubleshooting Ice machine disposition Possible causes Corrective action Legend: ON or OFF FLASHING Ice machine is in running 1. Defective compressor. 1. Replace compressor. condition but not making ice. 2. Defective start relay. 2. Replace start relay. 3. Defective start capacitor. 3. - Page 23 Warranty Registration and Equipment Evaluation Thank you for purchasing Follett Products LLC equipment. Our goal is to earn your complete satisfaction by delivering high-value products and services backed by outstanding customer and technical support. Please review the installation instructions thoroughly. It is important that the installation be performed to factory specifications so your equipment operates at its maximum efficiency.
- Page 24 Horizon Elite, Ice Manager, SafeCLEAN Plus, SaniSponge and Vision are trademarks of Follett Products, LLC. Chewblet, RIDE and Follett are registered trademarks of Follett Products, LLC, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01252592R08 www.follettice.com...
