- Page 1 Horizon Elite Ice Machine Installation Instructions ™ for Remote Condensing Unit D1010R, D1410R 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 www.follettice.com 01113356R05...
- Page 2 Horizon Elite 1010CU Horizon Elite 1410CU W1 Width 39.9" (101.3 cm) – Model ASAFR9510ZNAMC1, 39.9" (101.3 cm) – Model ASFS9516ZNAMC1 37.75" (95,9 cm) – three phase (Larkin) ASFR9511ZFAMC1 36.25" (91.4 cm) – Models AJA7490ZXDPN and AWA9490ZXTPN D1 Depth 28.5" (72.4 cm) – Model ASAFR9510ZNAMC1, 28.5"...
-
Page 3: Site Preparation
Prior to installation, carefully unpack and inspect the contents of your condensing unit! Site preparation To ensure proper performance, ease of service and warranty coverage, it is critical that you follow the requirements detailed in this manual. If you cannot meet these requirements or have questions, call our technical service group at 877.612.5086 for installation support. -
Page 4: Site Layout
Condenser installation specifications CONDENSER UNIT 100' max. ➍ (30.5 m) maximum ➊ line rise P-trap ➋ S-trap required required ➊ +35' (+10.7 m) +20' (+6.1 m) Easton Pennsylvania MODEL CORPORATION SERIAL NO PART NO FULL LOAD AMPS VOLTS PHASE SINGLE REFRIGERANT MOTOR COMPRESSOR THERMALLY PROTECTED CHARGE... -
Page 5: Condenser Installation
Electrical requirements CAUTION • Electrical disconnects required within 10' (3 m) for all hard wired connections • Install in accordance with NEC and local electrical codes Horizon Elite 1010CU Horizon Elite 1410CU Minimum circuit ampacity single phase – 10.7A single phase – 19.3A (Tecumseh AWA9513ZXDPN) three phase –... - Page 6 Electrical connections at contactor • Electrical disconnects required within 10' (3 m) for all hard wired Single Phase ELECTRICAL connections. DISCONNECT • Install in accordance with NEC and local electrical codes. POWER SUPPLY 230-60-1 COMPRESSOR CONTACTOR NC AUXILIARY SWITCH CRANK CASE HEATER COMPRESSOR CONTACTOR...
- Page 7 Phase monitor adjustments (if necessary) 1. Use a meter at the phase monitor to ensure there is voltage across all three phases and note the voltage value. 2. The Voltage Adjustment (VAC) should be set to match the voltage value from Step 1. 3.
-
Page 8: Refrigeration Line Installation
Refrigeration line installation Refrigeration line installation: 5/8" suction / 3/8" liquid line (1010, 1410) CAUTION • The installer of the refrigeration line set must be USA Government Environmental Protection Agency (EPA) certified in proper refrigeration handling and service procedures • A qualified person must perform all roof or wall penetration •... -
Page 9: Pressure Adjustment
Pressure adjustment Set low-pressure switch - if applicable EXAMPLE DIFFERENTIAL CUT-IN ADJUSTMENT Di erential Cut Out Cut In ADJUSTMENT SCREW = 10 SCREW 1) Adjust the top LEFT screw until the pointer is set to 10 (the di erential). Di erential Cut In 2) Adjust the top RIGHT LBS. - Page 10 3. Install hail hood (5) to brackets using the remaining six screws (6). Note: The bottom hole in the bracket is not used when mounting the hail hood (7). NOT USED Install hail hood (Larkin units only) 1. Hail hood comes factory mounted.
-
Page 11: Start Up And Test
Start up and test NOTICE Ice machine MUST be cleaned and sanitized prior to operation! Consult Operation and Service Manual provided with ice machine for cleaning and sanitizing instructions. Verify operation • Turn dispenser power ON if applicable • Check current draw of compressor to verify correct electrical operation •... - Page 12 Horizon Elite, Ice Manager, and Vision are trademarks of Follett Products, LLC. Chewblet, RIDE and Follett are registered trademarks of Follett Products, LLC, registered in US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01113356R05 www.follettice.com...
