- Page 1 INSTRUCTION BOOK FOR Contour Electrol ® ®...
-
Page 2: Important Safety Instructions
Important Safety Instructions Pre-Installation 1. Carefully unpack screen and remove outer wrapping When using your video equipment, basic safety precautions from case. should always be followed, including the following: 2. Set aside the Installation Kit. Items inside will be used Read and understand all instructions before using. - Page 3 Installation (continued) 3. Make sure the bracket is level. 4. Hang the screen case on the wall mount bracket as shown in (Figure 2). Be sure the case is fully seated on the bracket. Wall 5. Tighten the two stop screws against the wall mount bracket using a #2 Phillips screwdriver (Figure 1).
-
Page 4: Electrical Installation
Electrical Installation 1. Open the junction box on the left end of the case using a #2 Phillips screwdriver. Install electrical connections that apply to your unit. Make sure to review the wiring diagram for proper hook up. Replace the junction box cover. NOTE: Must be installed in accordance with the requirements of the Local Building Codes, the Canadian Electrical Code (CEC), CAN/CSA C22.1 and the National Electric Code (NEC),... - Page 5 Screen Adjustment for 120V Screens Locate the wall switch and remove the cover plate from the Press and hold the up button until the desired up position is wall switch and remove the switch from the junction box. reached. If you travel too far up, press the down button to move the screen downward.
- Page 6 Contour Electrol Installation for 120V Screens ® ® 120V Wiring Diagram 3-conductor 20–24 gauge wire can be used in place of the IMPORTANT NOTE: The wall switch is REQUIRED to make any S T O supplied RJ-14 cable to connect the wall switch. Connect the BUS limit switch adjustments, EVEN if a third party control system is terminals on the wall switch to the corresponding BUS terminals used.
- Page 7 Contour Electrol Installation for 120V Screens ® ® 120V Wiring Diagram with Optional Built-In Video Projector Interface CAUTION: The projector must be turned off before IMPORTANT NOTE: The wall switch is REQUIRED to make any connecting the trigger wires to the projector. Failure to limit switch adjustments, EVEN if a third party control system is do so may damage the controller.
- Page 8 Contour Electrol Installation for 220/240V Screens ® ® 240V Wiring Diagram ILT RJ-9 Pin-Outs (Tab Is Facing Up) IMPORTANT NOTE: The wall switch is REQUIRED to make any Green IR or Up Black limit switch adjustments, EVEN if a third party control system is Ground Common used.
-
Page 9: Troubleshooting
Troubleshooting Visit www.da -lite.com to find installation and troubleshooting You can contact us by email at info@da-lite.com or by phone at tutorials. You will also find a link to Live Chat for interactive 800.622.3737 or 574.267.8101 with any additional troubleshooting support. - Page 12 OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE. In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137, Warsaw, IN 46581-0137, (574) 267-8101, (800) 622-3737.
