Griven Chiron 1 B RP User Manual

Advertisement

Quick Links

Chiron B RP
1 - 2- 3 - 4
Code / Codice
Power consumption
Consumo di energia
Power supply
Alimentazione elettrica
Electrical Class
Classe elettrica
Weight / Peso
Operating temperature
Temperatura di funzionamento
IK rating / Grado IK
IP rating / Grado IP
Size / Dimensioni
Chiron 1
Chiron 2 - 622 mm [24,49"]
Chiron 3 - 934 mm [36,77"]
Chiron 4 - 1246 mm [49,06"]
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
User Manual
551157 Rev. 9.0
Date: 05/02/2025
Chiron 1
AL5352
14.4W
0.545 Kg / 1,2 lb
IK07
310
12,20
Tel. +39.0376.779483
Fax +39.0376.779682
E-mail: sales@griven.com
Web: www.griven.com
Chiron 2
AL5353
28.8W
48V DC
III
1.1 Kg / 2.4 lb
-40°C to 50°C /-40°F to 122°F
IK08
IP67
© Copyright Griven 2020 - GRIVEN S.r.l. is continuously
developing and improving all its products.
We reserve the right to change specifications without
prior notification
Chiron 3
AL5354
43.2W
1.6 Kg / 3.5 lb
2.2 Kg / 4,8 lb
IK08
Chiron 4
AL5355
57.6W
IK08
35
1,38
page 1 of 7

Advertisement

loading
Need help?

Need help?

Do you have a question about the Chiron 1 B RP and is the answer not in the manual?

Questions and answers

Summary of Contents for Griven Chiron 1 B RP

  • Page 1 Chiron 2 - 622 mm [24,49”] Chiron 3 - 934 mm [36,77”] Chiron 4 - 1246 mm [49,06”] page 1 of 7 © Copyright Griven 2020 - GRIVEN S.r.l. is continuously Griven S.r.l. - Via Bulgaria, 16 Tel. +39.0376.779483 developing and improving all its products.
  • Page 2 Important notices / Avvisi Importanti - This product must be installed in accordance with applicable national and local electrical and construction codes by a person familiar with the construction and operation of the product and the hazards involved. Failure to comply with the following installation instructions may result in death or serious injury.
  • Page 3 CAUTION: The luminarie should be positioned so that prolonged starting into the luminarie at a distance closer than 3 meters is not expected. ATTENZIONE! L’apparecchio deve essere posizionato in modo che non si possa fissarlo a lungo a una distanza inferiore di 3 metri.
  • Page 4 Connection / Connessioni Cable type ( Power in ) - 2x1,5 mm^2 - L= 500 mm Tipo di cavo ( Power in ) - 2x1,5 mm^2 - L= 500 mm POWER IN 220 - 240 VAC 50 - 60 Hz +V(Red ) (Green/ Yellow) POWER SUPPLY UNIT...
  • Page 5 Connection / Connessioni Con guration scheme CHIRON - DALI Con gurazione schema CHIRON - DALI DALI AL8356 - IP20 1248 DALI DIMMER Con guration scheme CHIRON - DMX Con gurazione schema CHIRON - DMX AL8296 - IP20 1248 DMX 0/1-10V 0/1-10V AL8295 - IP20 1248 0/1-10V Power Input...
  • Page 6 Fixing / Fissaggio AL8342 Flat Fixing Plate This side to the wall Size 2.5 (ISO) 1 = from 90 to 230 mm Allen key 2 = from 90 to 545 mm Chiave brugola 3 = from 90 to 857 mm Dimensione 2.5 (ISO) 4 = from 90 to 1169 mm Fixing Brackets / Fissaggio Forcelle...
  • Page 7 Fixing Brackets for Spot Optics / Forcelle per Ottica Spot AL8466 Fixing Brackets 160mm Size 2.5 (ISO) Allen key Chiave brugola Dimensione 2.5 (ISO) 1 = from 90 to 215 mm 2 = from 90 to 527 mm 3 = from 90 to 839 mm 4 = from 90 to 1158 mm -90˚...

This manual is also suitable for:

Chiron 2 b rpChiron 3 b rpChiron 4 b rpAl5352Al5353Al5354 ... Show all
