Griven Parade L MC 1 User Manual

Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Parade L MC
1 / 2 / 3 / 4
Code / Codice
Power consumption
Consumo di energia
Nominal current
Corrente nominale
Power supply
Alimentazione elettrica
Inrush current / Corrente di
spunto
Power factor / Fattore di potenza
Electrical class / Classe elettrica
Weight / Peso
Operating temperature
Temperatura di funzionamento
IP rating / Grado IP
IK rating / Grado IK
Dimensions - Dimensioni
Parade L MC 1
Parade L MC 2
Parade L MC 3
Parade L MC 4
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
User's Manual
Rev. 1.0
Date: 26/07/2022
Parade L MC 1
AL8030
20W
0.1A @230Vac
23.42 A @240VAC, 25°C
cos.φ= 0.87
2.1 Kg
318 mm
[12.5"]
610 mm [24"]
914 mm [36"]
1219 mm [48"]
Tel. +39.0376.779483
E-mail: sales@griven.com
Web: www.griven.com
Parade L MC 2
AL8035
37W
0.17A @230Vac
220-240VAC 50/60Hz
cos.φ= 0.94
3.1 Kg
-40°C to +50°C ( -40°F to 122°F )
IP67
IK09
© Copyright Griven 2020 - GRIVEN S.r.l. is continuously
developing and improving all its products.
We reserve the right to change specifications without
prior notification
Parade L MC 3
AL8040
54W
0.25A @230Vac
27.5 A @240VAC, 25°C
cos.φ= 0.95
I
4.4 Kg
76 mm
[3"]
551112
Parade L MC 4
AL8045
73W
0.33A @230Vac
cos.φ= 0.97
5.6 Kg
page 1 of 8
