LB-1 / LB-2 / LB-3
Code / Codice
Power consumption
Consumo di energia
Power supply
Alimentazione elettrica
Inrush current
Corrente di spunto
Power factor
Fattore di potenza
Electrical class
Classe elettrica
Weight / Peso
Operating temperature
Temperatura di funzionamento
IP rating / Grado IP
IK rating / Grado IK
Dimensions / Dimensioni
Parade LB-1
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
User Manual
Rev. 1.0
Date: 20/12/2021
Parade LB1
AL5260
0.1A@230V /20W
2.1 Kg / 3.97 lb
IK09
318 mm
[12.5"]
610 mm [24"]
Parade LB-2
914 mm [36"]
Parade LB-3
Tel. +39.0376.779483
E-mail: sales@griven.com
Web: www.griven.com
Parade LB2
AL5265
0.18A@230V / 40W
120-277VAC / 50-60Hz
<200mA²s @ 230V/50Hz
cos.φ= 0.97
I
2.8 Kg / 6.17 lb
-20°C to +50°C ( -4°F to 122°F )
IP67
IK10
© Copyright Griven 2020 - GRIVEN S.r.l. is continuously
developing and improving all its products.
We reserve the right to change specifications without
prior notification
551111
Parade LB3
AL5270
0.27A@230V / 58W
4.4 Kg / 9.7 lb
IK09
76 mm
[3"]
page 1 of 4
