Akia Screens Motorized Series User Manual

Important Safety & Warning Precautions
Make sure to read this user's guide and follow the procedures below.
AKIA Screens allows a 1.5% tolerance within the viewing surface for expansion and contraction of the screen
materials over time.
Caution: The screen's Black Top Drop is already set to its maximum drop distance. There is NO extra Black Top
Drop in the roller. Please be aware of this as it will void your warranty with AKIA Screens. Unapproved changes
or modifications (except for cutting the power cord for hardwire installations) to this unit are prohibited and will
void your warranty. For more information, please contact our Technical Support Department.
SCREEN MAINTAINANCE
Dust, dirt and scratches on the projection screen surface will affect the quality and performance of the
projection image. For optimal results we advise to pay attention to the following instructions.
1. Materials needed: Two Lint-Free white cloths, Mild Soap (hand soap is suitable) and Water.
2. Take the Lint-Free cloth and submerge it in warm water for cleaning light dust and dirt. For stubborn stains or
a sticky surface, a solution of hand soap diluted with warm water should be used.
3. Completely ring out cloth so it is lightly dampened, not drenched.
4. Using the damp cloth, lightly wipe in an up and down motion starting at the left of the screen moving to the
right of the screen. DO NOT WIPE IN CIRCULAR MOTION.
5. Once you have completed wiping the entire screen with a dampened Lint-Free cloth, use the dry Lint-Free cloth
to wipe off any excess water from the screen
Notes: The following precautions should be followed to avoid damaging the material, which is not
covered under warranty.
• Don't scratch the material, as it will leave permanent markings on the screen's surface.
• Don't point to the screen material with a fingertip or other sharp objects to prevent damage to the material.
• Don't use acetone, benzene, alcohol and any other organic solvents to clean the screen material. Using such
chemicals will permanently damage the screen.
Please retain this user's guide for future reference.
• To avoid damaging the unit, do not use with any unauthorized accessories not recommended by the
manufacturer.
• Handle the unit carefully during transportation to avoid any damages.
• To ensure safe and reliable operation, direct connection to a properly grounded power source is advised.
• The power outlet supplying power to the unit should be close to the unit and easily accessible.
• Do not install the unit on uneven or inclined surfaces.
• Do not put heavy objects on the power cord and position it properly to avoid creating a trip obstacle.
Rev. V04232024DT (DZUG0158)
Electric Wall/Ceiling Projection Screen
1
Motorized Series
User's Guide – EN type
(RC1) V1.0
www.akiascreens.com
