Product Description:
The EDGE FREE® CineWhite® UHD-B Series is a fixed frame projection screen that uses Akia's EDGE FREE®
technology. The EDGE FREE® design resembles a flat panel TV display. The EDGE FREE® CineWhite ® includes
a micro-thin bezel trim to further enhance the frame appearance and absorb projector overshoot.
The screen material included is our ISF certified CineWhite® UHD-B, which is a reference quality front projection
material with black backing that is certified by the world-renowned Imaging Science Foundation. ISF Certified means
the CineWhite UHD-B material produces accurate colors in a light-controlled dark room environment. This is an
industry standard for high-fidelity video display systems. Watch your content as the director intended!
In order for the CineWhite® UHD-B to maintain its projection qualities and optimum performance,
please refer to the list below for proper maintenance and cleaning.
• Use a dry microfiber cloth to remove dust from the screen's surface.
• When cleaning, use a damp microfiber cloth with warm water to remove any marks.
• Never rub or apply pressure when cleaning the surface.
• Never attempt to use any solutions, chemicals or abrasive cleaners on the screen surface.
• In order to avoid damaging the screen, avoid touching it directly with your fingers,
pens/pencils or any other sharp or abrasive objects.
JA01072022
EDGE FREE® CineWhite® UHD-B Series
www.akiascreens.com
Matte White Fixed Frame Screen
USER'S GUIDE – M Type
U-00239
V1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDGE FREE CineWhite UHD-B Series and is the answer not in the manual?

Questions and answers

Related Manuals for Akia Screens EDGE FREE CineWhite UHD-B Series

Summary of Contents for Akia Screens EDGE FREE CineWhite UHD-B Series

  • Page 1 EDGE FREE® CineWhite® UHD-B Series Matte White Fixed Frame Screen USER’S GUIDE – M Type Product Description: The EDGE FREE® CineWhite® UHD-B Series is a fixed frame projection screen that uses Akia’s EDGE FREE® technology. The EDGE FREE® design resembles a flat panel TV display. The EDGE FREE® CineWhite ® includes a micro-thin bezel trim to further enhance the frame appearance and absorb projector overshoot.
  • Page 2 1. Frame and Edge Trim Parts List 2 pcs 2 pcs Main Frame Parts Edge Trim Parts item item vertical frame Part A. Part D. ½ horizontal frame Part B. Part E. ½ horizontal frame Part C. Part F. 2. Hardware Parts List M4*4 D5*4 M4*4...

  • Page 3: Frame Assembly

    100'' 125'' 145” Item Parts List Center Joints- M4 (bottom position) Center Joints-D5 (top position) Elbow Joints M4 (bottom position) Elbow Joints D5 (top position) Side cover Center Joints- M4 Side cover Elbow Joints M4 M4x7 Screws Spring Spring Hook wall brackets Φ5x50 Wall Screws Hollow Wall anchors...

  • Page 4: Back Side

    Step 5: Secure the elbow joints by fastening them with M4x7 screws ( , 4 at each corner. Screen Material Step 6: Put on the white gloves (p) and carefully unroll the screen material on a clean surface from the roller to the other side as shown below.

  • Page 5: Center Support Bar

    Center Support Bar Step9: Insert the Center Support Bar (o) into the upper top groove on the back of the frame with the bottom end near the approximate center point of the frame and rotate it in at an angle so that both ends of the bar are in alignment with the groove.
  • Page 6 Note (after all springs have been attached): Correct material installation –Corners of the screen material are properly wrapped around the corner edges of the frame and material is evenly tensioned and flat, creating a nicely taut surface. Incorrect material installation –The corners of the screen material are not properly wrapped along the edge of the frame leaving the material with unbalanced tension and an uneven finish.
  • Page 7 Connect edge trim frames (e/f) together using the M4 center joint (e) and secure with four of the M4x4 screws (m) as show in Step 1. Repeat for other side. Once both top and bottom edge trim frames have been connected, attach the vertical (left/right) sides edge trim frames (d) using the elbow joints (f) and secure with four M4x4 screws (m) on all corners, Step 2.

  • Page 8: Wall Installation

    Step 15: Begin by placing the frame on the bottom bracket, move up and position onto the top wall brackets as shown below and push down at the center of the top of the frame to secure. For Technical Support or an Akia Screens contact in your area, visit www.akiascreens.com JA01072022 www.akiascreens.com...
