Akia Screens EDGE FREE CLR 2 Series User Manual

Product Description:
The EDGE FREE® CLR® 2 Series is a fixed frame projection screen that uses Akia's EDGE FREE® technology.
The EDGE FREE® design resembles a giant size flat panel TV display. The screen includes a bezel trim to further
enhance the frame appearance and absorb projector overshoot. An optional LED kit is available for backlighting.
The screen material included is our ISF Certified CLR® 2 (Ceiling Light Rejecting) which is a front projection
material designed for ultra and short throw projectors, precisely formulated for environments with minimal control of
overhead room lighting. Its multi-layer structure enhances picture brightness, maintain color purity, and improves
contrast levels in ambient light room environments. The CLR® 2 is best for family rooms, educational facilities,
conference rooms, house of worship or any applications in which incident light is a factor.
Screen Maintenance
Dust, dirt and scratches on the projection screen surface will affect the quality and performance of the projection
image. For optimal results we advise to pay attention to the following instructions.
1) Use a dry microfiber cloth or soft brush to remove dust from the screen's surface.
2) When cleaning, use a damp microfiber cloth with warm water to remove any marks.
3) Never rub or apply pressure when cleaning the surface
4) The screen material has a scratch-resistant layer to protect the material through many years of use.
Notes：The following precautions should always be followed to avoid damaging the material, which is not covered
under warranty.
▪ Don't touch the screen material with your bare hands to avoid leaving oil residue from fingertips.
Use gloves when handling the material.
▪ Don't point to the screen material with a fingertip or other sharp objects to prevent damage to the material.
▪ Don't use acetone, benzene, alcohol and any other organic solvents to clean the screen material.
Using such chemicals will permanently damage the screen.
Qty
item
Part A.
Part B.
Part C.
10042022JA
1. Frame and Edge Trim Parts List
2 pcs
Main Frame Parts
vertical frame
½ horizontal frame
½ horizontal frame
www.akiascreens.com
EDGE FREE® CLR® 2 Series
Ceiling Light Rejecting Fixed Frame Screen
Qty
item
Part D.
Part E.
Part F.
USER'S GUIDE – V1.1
2 pcs
Edge Trim Parts
U-00232
1
