Panel Ready Installation

The appliance is designed to be panel ready. To install a custom panel on the front of the doors of your
appliance, follow the steps below:
Overlay Panel
Dimension:
Door Panel Width:
587mm ( 23 1/8" )
Door Panel Height:
742mm ( 29 1/4" )
Door Panel Depth:
19mm ( 3/4" ) max
Door Panel Weight:
10 lb. max
Viewable Area Width:
451mm ( 17 3/4" )
Viewable Area Height:
569mm ( 22 3/8" )
10
