  • Page 1 User Manual Uninterruptible Power Supply System...

  • Page 2: Table Of Contents

    Table of content 1. Introduction Thank you for purchasing the smart interactive sine wave uninterruptible power supply system (UPS) from the Forza SI series. To enjoy 1. Important safety warnings all features and benefits of this device, please read and follow all installation and operation instructions thoroughly before unpacking, installing, or operating this unit.

  • Page 3: Installation And Setup

    CAUTION WARNING: Risk of electric shock. Only for 110/120 VAC system: • Even after the unit is disconnected from the mains (building wiring outlet), components inside the UPS system are still NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 connected to the battery and electrically live and dangerous.

  • Page 4: Install The Ups

    2.3. Install the UPS Install UPS and external battery For safety consideration, the UPS is shipped out from factory without connecting battery wires. Before installing the UPS, please follow the steps below to re-connect battery wires first. 2.3.1 Initial setup •...

  • Page 5: Battery Replacement

    Step 4: Network connection To connect an external battery pack: Network/Fax/Phone surge port 1. Turn off the UPS utility input. 2. Open the front-left cover on the UPS and the battery pack first. And disconnect the internal battery cable. 3. Remove the external battery covers from the UPS and the battery pack. Connect one end of the external battery cable to the UPS and the other end to the battery pack as shown in the illustration above.

  • Page 6: Battery Kits Assembly (Optional)

    2.5 Battery Kit Assembly (optional) Step 2 Step 3 Step 1 Note: Please assemble the battery kit before installing it inside of UPS. Make sure to select the correct battery kit assembly Disconnect battery wires. Pull out the battery box by removing Remove front panel.

  • Page 7: Lcd Panel

    Button Function Display Function Backup time information ON/MUTE button • Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to turn on the UPS. • Mute the alarm: After the UPS is turned on in battery mode, press and hold this button for at Indicates the estimated backup time.

  • Page 8: Audible Alarm

    3.5 UPS setting Indicates low battery. Indicates the battery is fault. Output voltage information Indicates the output voltage and output frequency. V: voltage, Hz: frequency Indicates the load or the UPS output is short circuited. There are two parameters to set up the UPS: 3.3 Audible alarm Parameter 1: For program alternatives.
  • Page 9 04: Maximum charger current setting 00: Exit setting Interface Setting Interface Setting Parameter 3: Set up the maximum charger current. Exit the setting mode. 1/2/4/6/8: setting the maximum charger current at 1/2/4/6/8 Ampere. (Default: 8A) Note: This setting is only effective for super charger 06: Autonomy limitation setting Steps for setting programmable outlets.

  • Page 10: Operating Mode Description

    3.6 Operating mode description 3-7. Fault codes Operating mode Description LCD display Fault Icon Fault Fault event Fault event Icon code code When the input voltage is within voltage regulated ECO mode Bus start fail Inverter output short range, UPS will power the output directly from the mains.

  • Page 11: Troubleshooting Guide

    4. Troubleshooting guide If the UPS system does not operate correctly, please solve the problem following the guidelines in the table below. Symptom Possible cause Remedy Fault code is shown as 45 on LCD The charger does not have output Contact your dealer.
  • Page 12 SNMP, RS-232, USB Power management software ForzaTracker Forza Power Technologies LLC. Forza® is a registered trademark. All rights reserved. All other trademarks and brand names are registered trademarks of their respective owners. Specifications are subject to change without notice. Made in China.
